5, For EDID ID settings, press the UP or DOWN button until the LED screen shows
"E00" (in which "E" refers to EDID, "00" to EDID ID). Press and hold UP + DOWN
buttons for 5 seconds, then release to enter the "EDID Settings" mode. The EDID ID
number (e.g. E01) on the LED screen will flash at 1Hz, then press the UP or DOWN
button to select the EDID ID you desired, then press and hold UP + DOWN buttons
for 5 seconds to confirm the setting and stop flashing.
The corresponding EDID ID is as follows:
EDID ID
00
01
02
03
04
05
06
07
08
Notes:
(1) H refers to HDMI; D refers to DVI. (The default EDID of 1080p60 will be used if you
have not previously copied the EDID to ID 06 or downloaded EDID to ID 07/08 on
the controller box web page.)
(2) EDID ID 06/07/08 is not available without Controller Box.
6, For audio options settings, press the UP or DOWN button until the LED screen shows
"AHE" (in which "A" refers to Audio and "HE" to HDMI EMB). Press and hold UP +
DOWN buttons for 5 seconds, then release to enter the "AUDIO Settings" mode. The
audio option (AHE or AEI) on the LED screen will flash at 1Hz, then press the UP or
DOWN button to select the AUDIO option, then press and hold UP + DOWN buttons
for 5 seconds to confirm the setting and stop flashing.
The corresponding audio options are as follows:
AHE: Use HDMI Audio
AEI: Use external Audio In
EDID Description
H1080P60_2CH
H720P60_2CH
D1024P60
D1080P60
D1200P60
H1200P60_2CH
COPY
USER1
USER2
