Hardware - SitOnit Seating Surge C-Leg Assembly Instructions Manual

Surge
Parts
•
Hand Control (1)
•
Control Box (1)
•
Cam Lock (2)
•
Hairpin Clip (2)
•
Extension Cable (2v)
•
A/C Cable (1)
•
Cable Management
•
Cable Clip (4)
•
Small P-Clip (10)
Control
Box
Cable Clips
Small P-Clip

HARDWARE

M3 x 20 mm
Screws
ASSEMBLY INSTRUCTIONS
Extension
M3.5 x 16 mm
Screws
•
Hardware
•
M3 x 20 mm Screw (3)
•
M5 x 20 mm Screw (12)
•
M5 x 25 mm (2)
•
M3.5 x 16 mm Screw (10)
Cam
Lock
Hairpin
Clip
Cable
M5 x 20 mm
Screws
C6772 Rev B
Hand
Control
A/C Cable
M5 x 25mm
Screws
|
