Binary B-200-1CAT-VGA Owner's Manual

SPECIFICATIONS
Unit Dimensions 92mm (3.6") x 153mm (6") x 25mm (1")
(metal box without mounting tabs)
Weight (stand alone box) 2.8
Transmission Distance 1000 Feet (330 m) (Cat5e)
Video Support VESA
Video Bandwidth 350 MHz
Video Transmission Up to WUXGA, 1920 x 1200, 60 Hz
& Supports 720p component signal
Audio Support No
Adjustable Equalization & Gain Control Yes
Equalization Type Analog
RGB Delay Control (De-Skew) Yes
RJ 45 Termination EIA/TIA-568-B termination (T568B)
Tabeletop & Wall Mounting Yes
Locking Power Jack Yes
ESD Protection Human Body (air gap): 19kV
Human Body (contact): 12kV
Internal Chipset: 8kV
Power Supply 5VDC, 4A
Power Consumption 5 Watts
WARRANTY
2-Year Limited Warranty
Binary™ Products have a 2-Year Limited Warranty. This warranty includes parts and labor repairs on all
components found to be defective in material or workmanship under normal conditions of use. This
warranty shall not apply to products which have been abused, modified or disassembled. Products to
be repaired under this warranty must be returned to Snap AV or a designated service center with prior
notification and an assigned return authorization number (RA).
*Technical Support # 1-866-838-5052
OWNER'S MANUAL
B-200-1CAT-VGA
Welcome to the Binary™ brand of products
This product is designed to provide years of exceptional reliability. Binary™ is one of the most highly
regarded brands available today. We appreciate your business and we stand committed to providing
our customers with the highest degree of quality and service in the industry.
Binary™ Single Cat-5 Extender for
>>
VGA (WUXGA) with RGB Delay Control
