Power Supply Board Terminal Identification:

Terminal
Function/Description
Legend
Connect 220VAC 50/60Hz to these terminals: L to hot, N to neutral .
L, G, N
Do not use the [G] terminal
+ DC – Refer to MaximalFEV Series Configuration Chart, pg. 4.
Trigger EOL Fire Alarm Interface trigger input from a short or FACP .
Supervised Trigger inputs can be normally open, normally closed from an FACP output circuit .
NO, GND
FACP interface latching or non-latching .
RESET
+ AUX – Auxiliary Power-Limited output rated @ 1A (unswitched) .
AC Fail Indicates loss of AC power, e .g . connect to audible device or alarm panel .
NC, C, NO Relay normally energized when AC power is present . Contact rating 1A @ 30VDC .
Indicates low battery condition, e .g . connect to alarm panel . Relay normally energized when
Bat Fail
DC power is present . Contact rating 1A @ 30VDC . A removed battery is reported within 5
NC, C, NO
minutes . Battery reconnection is reported within 1 minute .
– BAT + Stand-by battery connections . Maximum charge current 1 .54A .

Power Supply Board Stand-by Battery Specifications

eFlow4NBV:
Battery
7AH
12AH
40AH
65AH
eFlow6NBV:
Battery
7AH
12AH
40AH
65AH
eFlow102NBV:
Battery
7AH
12AH
40AH
65AH
eFlow104NBV:
Battery
7AH
12AH
40AH
65AH
- 6 -
Access Control Applications Stand-by
30 Mins ./4A*
35 Mins ./4A*
Over 4 Hours/4A*
Over 4 Hours/4A*
Access Control Applications Stand-by
10 Mins ./6A
30 Mins ./6A*
Over 4 Hours/6A*
Over 4 Hours/6A*
Access Control Applications Stand-by
5 Mins ./10A
30 Mins ./10A*
Over 2 Hours/10A*
Over 4 Hours/10A*
Access Control Applications Stand-by
5 Mins ./10A
30 Mins ./10A*
Over 2 Hours/10A*
Over 4 Hours/10A*
