Power Supply Board Terminal Identification - Altronix Maximal Series Installation Manual

Terminal
Function/Description
Legend
L, G, N Connect 120VAC 60Hz to these terminals: L to hot, N to neutral. Do not use the [G] terminal
+ DC – Refer to MaximalFE Series Configuration Chart, pg. 3.
Trigger EOL Fire Alarm Interface trigger input from a short or FACP. Trigger inputs can be normally open,
Supervised normally closed from an FACP output circuit (power-limited input).
NO, GND
FACP interface latching or non-latching (power-limited).
RESET
+ AUX – Auxiliary Power-Limited output rated @ 1 amp (unswitched) (power-limited output) .
AC Fail Indicates loss of AC power, e.g. connect to audible device or alarm panel. Relay normally energized
NC, C, NO when AC power is present. Contact rating 1 amp @ 30VDC (power-limited).
Indicates low battery condition, e.g. connect to alarm panel. Relay normally energized when DC power
Bat Fail
is present. Contact rating 1 amp @ 30VDC. A removed battery is reported within 5 minutes.
NC, C, NO
Battery reconnection is reported within 1 minute (power-limited).
– BAT + Stand-by battery connections. Maximum charge current 1.54 amp (non power-limited).
eFlow4NB:
Battery
7AH
12AH
40AH
65AH
eFlow6NB:
Battery
7AH
12AH
40AH
65AH
eFlow102NB:
Battery
7AH
12AH
40AH
65AH
eFlow104NB:
Battery
7AH
12AH
40AH
65AH
*Only these configurations can be utilized in ULC-S319 installations.
Maximal Expandable Power Systems

Power Supply Board Terminal Identification:

Power Supply Board Stand-by Battery Specifications
Access Control Applications Stand-by
30 Mins./4 amp*
35 Mins./4 amp*
Over 4 Hours/4 amp*
Over 4 Hours/4 amp*
Access Control Applications Stand-by
10 Mins./6 amp
30 Mins./6 amp*
Over 4 Hours/6 amp*
Over 4 Hours/6 amp*
Access Control Applications Stand-by
5 Mins./10 amp
30 Mins./10 amp*
Over 2 Hours/10 amp*
Over 4 Hours/10 amp*
Access Control Applications Stand-by
5 Mins./10 amp
30 Mins./10 amp*
Over 2 Hours/10 amp*
Over 4 Hours/10 amp*
- 5 -
