Manual IP

In this submenu, you can configure the IP address manually:
Press the UP/DOWN buttons to position the cursor on the number you want to change. The
adjustment range for each number is 0–255.
Press the ENTER button to confirm the selection.
Press the UP/DOWN buttons to select the desired value.
Press the ENTER button to confirm the selection.
Repeat step 1–4 as required.
Press the UP/DOWN buttons to position the cursor on Cancel or Enter.
Press the ENTER button to cancel or confirm the changes.

Set Netmask

In this menu, you can set the netmask of the IP address to one of the following three options.
Press the UP/DOWN buttons to select the netmask.
Press the ENTER button to confirm the selection.

Set DMX Port

In this menu, you can configure the DMX port settings.
Press the UP/DOWN buttons to select one of the 4 DMX ports.
Press the ENTER button to confirm the selection.
Note:
The submenu that opens depends on the configuration of the port (DMX status: Output, Input or Disable).
● See 6.8.4.1. DMX Status: Output for more information.
● See 6.8.4.2. DMX Status: Input for more information.
● See 6.8.4.3. DMX Status: Disable for more information.
