NET-4/3 IP, 3-pin
To mount the device using the included hook-and-loop straps, follow the steps below:
Loosen the mounting bracket thumbscrews (17) and remove the mounting bracket (15), as shown in
Fig. 07.
Thread the hook-and-loop straps through the strap slots (14) to attach the device to the supporting
structure, as shown in Fig. 08. Make sure that the device cannot move freely.
Secure the device with a secondary suspension, for example a safety cable. Make sure that the
secondary suspension can hold 10 times the weight of the device. If possible, the secondary
suspension should be attached to a supporting structure independent of the primary suspension. Put
the safety cable through the safety eye (16), as shown in Fig. 08
Product code: 50817
12
Fig. 07
Fig. 08
