- Page 1 MANUAL ENGLISH Wipe Out 4-360 White Ordercode: 42563 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Wipe Out 4-360 White Table of contents Warning ....................................2 Unpacking Instructions ..............................2 LED Expected Lifespan ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains............................5 Return Procedure ................................6 Claims ....................................6 Description of the device .............................. -
Page 3: Warning
Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • Showtec Wipe Out 4-360 White • PowerCon to Schuko (1,5 m) •... - Page 4 • If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your Showtec dealer for service.
-
Page 5: Operating Determinations
Wipe Out 4-360 White • The user is responsible for correct positioning and operating of the Wipe Out. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. • This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to earth. -
Page 6: Connection With The Mains
Wipe Out 4-360 White The Wipe Out can be placed on a flat stage floor or mounted to any kind of truss with a clamp and 3 quicklocks. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. -
Page 7: Return Procedure
Wipe Out 4-360 White Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 8: Description Of The Device
Wipe Out 4-360 White Description of the device Features The Wipe Out 4-360 White is an efficient light effect with high output and great effects. • Sound Control • Input voltage: 100-240V, 60/50Hz • Power consumption: 52W • DMX channels: 1, 10, 14 •... -
Page 9: Frontside
Wipe Out 4-360 White Frontside Fig. 02 01) Moving head with 4 x 9W White lenses 02) LCD Display + control buttons 03) 5-pin DMX signal connector OUT 04) 5-pin DMX signal connector IN 05) Power switch ON/OFF 06) Fuse 5S3A/250V Backside Fig. -
Page 10: Set Up And Operation
Wipe Out 4-360 White Set Up and Operation Follow the directions below, as they pertain to your preferred operation mode. Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Connect the device to the main power supply. -
Page 11: Multiple Wipe Outs (Dmx Control)
Wipe Out 4-360 White Multiple Wipe Outs (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin or 5-pin XLR cable to connect the Wipe Outs and other devices. 04) Link the units as shown in fig. -
Page 12: Fixture Linking
Wipe Out 4-360 White Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 13: Control Panel
Wipe Out 4-360 White The Wipe Out 4-360 White can be operated with a controller in control mode or without the controller in stand-alone mode. Control Panel A) LCD display MODE button C) SETUP button D) UP button DOWN button Fig. -
Page 14: Menu Overview
Wipe Out 4-360 White Menu Overview See next page for the remaining menu functions. Ordercode: 42563... - Page 15 Wipe Out 4-360 White Ordercode: 42563...
-
Page 16: Main Menu Options
Wipe Out 4-360 White Main Menu Options Manual Mode Auto Mode Sound-controlled Mode DMX-512 Mode Master/Slave Mode Settings 1. Manual Mode 01) While in the main menu, press the UP and DOWN buttons until the display shows 02) Press the SETUP button to enter the menu. 03) Press the UP and DOWN buttons to toggle between the 3 options: ... -
Page 17: Auto Mode
Wipe Out 4-360 White 22) Press the UP and DOWN buttons until the display shows 23) Press the SETUP button to enter Pan adjustment. 24) Press the UP and DOWN buttons to toggle between the 4 options: p-Auto p-Manul ... -
Page 18: Dmx-512 Mode
Wipe Out 4-360 White 4. DMX-512 Mode 01) While in the main menu, press the UP and DOWN buttons until the display shows 02) Press the SETUP button to enter the menu. 03) Press the UP and DOWN buttons to toggle between the 2 options: ... - Page 19 Wipe Out 4-360 White 12) When the display shows , press the SETUP button to view the information about the output power. 13) Press the UP and DOWN buttons to view the information about the main or LED output power. 14) When the display shows , press the SETUP button to enter the menu.
-
Page 20: Dmx Channels
Wipe Out 4-360 White 41) Press the UP and DOWN buttons to toggle between the 2 options: history (general number of the corrections performed on the device) current (number of corrections performed on the device since it has been switched on) 42) Press the SETUP button to reset both, history and current status. -
Page 21: Channels
Wipe Out 4-360 White Channel 7 – LED 1 intensity 0-255 LED 1 intensity, from dark to bright Channel 8 – LED 2 intensity 0-255 LED 2 intensity, from dark to bright Channel 9 – LED 3 intensity 0-255 LED 3 intensity, from dark to bright Channel 10 –... - Page 22 Wipe Out 4-360 White Channel 12 – Functions Not functional 10-19 Manual mode. Use channels 1-6 to control the performance of the device 20-29 Built-in show 1 30-39 Built-in show 2 40-49 Built-in show 3 50-59 Built-in show 4 60-69 Built-in show 5 70-79 Built-in show 6...
-
Page 23: Maintenance
01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LED. Return the Wipe Out 4-360 White to your Showtec dealer. 03) The fuse. Replace the fuse. See page 22 for replacing the fuse. -
Page 24: No Response To Dmx
Wipe Out 4-360 White No Response to DMX Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction. 01) Check the DMX setting. Make sure that DMX addresses are correct. 02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power. Try your DMX control again. -
Page 25: Product Specifications
Wipe Out 4-360 White Product Specifications Model: Showtec Wipe Out 4-360 White Input Voltage: 100-240 VAC, 60/50Hz Power consumption: 52W (full output) DMX linking: 30pcs Fuse: 5S3A/250V Dimensions: 555 x 94 x 220 mm (LxWxH) Weight: 6,9 kg Operating and Programming:... -
Page 26: Dimensions
Wipe Out 4-360 White Dimensions Ordercode: 42563... -
Page 27: Notes
Wipe Out 4-360 White Notes Ordercode: 42563... - Page 28 ©2015 Showtec...
