1.1 Overview

This chapter provides a brief outline of the functions and features of the SuperServer
SYS-E200-12D-10C/8C/4C. It is based on the X12SDV-10C/8C/4C-SPT4F motherboard and
the CSE-101F chassis.
The following provides an overview of the specifications and capabilities.
Motherboard
Chassis
Processor
Support
Memory
Drive Support
Expansion Slots
I/O Ports*
System Cooling
Power
Form Factor
Notes: A Quick Reference Guide can be found on the product page of the Supermicro website.
The following safety models associated with the SYS-E200-12D-10C/8C/4C have been
certified as compliant with UL or CSA: 101F-18, 101F-A18X12.
Chapter 1
Introduction
System Overview
SYS-E200-12D-10C: X12SDV-10C-SPT4F
SYS-E200-12D-8C: X12SDV-8C-SPT4F
SYS-E200-12D-4C: X12SDV-4C-SPT4F
CSE-101F
SYS-E200-12D-10C: Single Intel Xeon® Processor D-1749NT
SYS-E200-12D-8C: Single Intel Xeon® Processor D-1736NT
SYS-E200-12D-4C: Single Intel Xeon® Processor D-1718T
Up to 128 GB ECC RDIMM, DDR4 2666 MHz or 128 GB ECC/non-ECC DDR4 2666
MHz memory
One M.2 (PCIe 4.0 x4/SATA 3.0, M-Key 2280)
N/A
Two RJ45 10GbE LAN ports
One dedicated RJ45 IPMI LAN port
Two SPF28 25GbE LAN ports
Two USB 3.0 Type A ports
One VGA port
Three 4-cm chassis fans
One external 180 watt DC power adapter
Mini-1U, (WxHxD) 7.7 x 1.7 x 8.9 in. ( 195 x 43 x 226 mm)
