Triton OMNICARE ULTRA CINCULT09W Manual

Electric shower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OMNICARE ULTRA
Elec tric Shower
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
R E TAIL VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
PRODUCT REGISTRATION IS ONLY AVAILABLE TO
UNITS PURCHASED & INSTALLED IN THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The shower installation MUST be carried out by a suitably qualified person, in the sequence of
this instruction book.
Design Registration:
EU - 008265516
UK - 6108473
IMPORTANT SAFETY ADVICE
Failure to use genuine Triton parts may cause
injury and invalidate your guarantee.
The shower unit MUST BE switched off at the
isolating switch when not in use. This is a safety
procedure recommended for all electrical
appliances.
2181638F - November 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OMNICARE ULTRA CINCULT09W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Triton OMNICARE ULTRA CINCULT09W

Summary of Contents for Triton OMNICARE ULTRA CINCULT09W

  • Page 1 NOTE DOWN THE PRODUCT CODE BELOW IMPORTANT SAFETY ADVICE (FROM THE FRONT OR TOP OF THE BOX) Failure to use genuine Triton parts may cause injury and invalidate your guarantee. The shower unit MUST BE switched off at the isolating switch when not in use. This is a safety procedure recommended for all electrical appliances.

  • Page 2: Important Safety Information

    PLEASE READ THIS IMPORTANT SAFETY INFORMATION Products manufactured by Triton are safe and without risk, provided they are installed, used and maintained in good working order in accordance with our instructions and recommendations. WARNING : DO NOT operate the shower if there is a possibility of frozen water within the heater or pipes feeding the shower.
  • Page 3 DO NOT operate the unit if the showerhead or spray hose becomes damaged. DO NOT restrict ow out of shower by placing showerhead in direct contact with your body. DO NOT operate the shower if water ceases to ow during use or if water has entered inside the unit because of an incorrectly tted cover.

  • Page 4: Introduction

    INTRODUCTION Please read this book thoroughly and familiarise yourself with all instructions before commencing installation Please keep it for future reference. The shower installation MUST be carried out by a suitably qualified person, in the sequence of this fitting instruction. ADVICE TO USERS Important: When first installed the unit will be empty.

  • Page 5: Omnicare Ultra Models

    Please see back of book for contact information. WEEE Directive – Policy Statement As a producer and a supplier of electric showers, Triton Showers is committed to the protection of the environment via our own environmental policy and the compliance with the WEEE directive.

  • Page 6: Table Of Contents

    CONTENTS Page Important Safety Information ............Introduction Advice to Users ................ Product Fiche ................Omnicare Ultra Models ............WEEE Policy Statement............. Specifications.................. Main Components ................. Dimensions, Water and Cable Entry Points ........Electrical .................. Plumbing ................Installation Requirements Plumbing ................Siting of the shower ..............

  • Page 7: Specifications

    SPECIFICATION ELECTRICAL Nominal Power Rating at 230V 8.0kW 9.0kW Nominal Power Rating at 240V 8.7kW 9.8kW 8.7kW - 40Amps Supply Fuse/Miniature Circuit Breaker (MCB) 9.8kW - 45Amps Residual Current Device (RCD) 30mA Isolation Switch 45Amp Double Pole Isolating Switch, with 3mm Minimum Contact Gap Supply Cable Maximum is 16mm, Refer to Electrical Requirements...

  • Page 8: Main Components

    MAIN COMPONENTS Inside the unit Inside the Cover 1. Top cable and pipe entry 8. Can and element assembly Water inlet 2. Bottom cable and pipe entry 9. Pressure switch Pressure relief device (PRD) 10. Thermostatic valve & 3. Rear cable and pipe entry Shower outlet maximum temperature selector 4.

  • Page 9: Dimensions, Water And Cable Entry Points

    SPECIFICATION DIMENSIONS & ENTRY POINTS 213mm 117mm Diagram Key: Water Entry Points 213mm 116mm Electrical Cable Entry Points...

  • Page 10: Plumbing

    INSTALLATION REQUIREMENTS PLUMBING REQUIREMENTS Refer to IMPORTANT SAFETY INFORMATION and SPECIFICATION sections before undertaking installation. Note: if the recommended dynamic pressure and flow is not available, there will be a noticeable reduction in flow from the shower head. If it is intended to operate the shower at pressures above the maximum or below the minimum stated, contact Customer Experience for advice.

  • Page 11: Siting Of The Shower

    INSTALLATION REQUIREMENTS WARNING Fig.1 Diagrammatic view (not to scale) The shower MUST NOT be positioned where For illustration purposes only. Kits may vary. it will be subjected to freezing conditions. Mains cold water supply Shower unit (either top, bottom can be mounted or rear entry) either side of riser rail...

  • Page 12: Electrical

    Contact a professional electrician/ local electricity company for advisement. 8. For close circuit protection DO NOT use a rewireable fuse. Instead use a suitably rated Miniature Circuit Breaker (MCB) or cartridge fuse. Triton recommend the following circuit protection: 8.7KW - 40Amp 9.8kW - 45Amp...
  • Page 13 INSTALLATION REQUIREMENTS 10. A 45 amp double pole isolating switch with a minimum contact gap of 3mm in both poles must be incorporated in the circuit (Fig.4). It must have a mechanical indicator showing when the switch is in the OFF position, and the wiring must be connected to the switch without the use of a plug or socket outlet.

  • Page 14: Installation

    INSTALLATION POSITIONING THE SHOWER For ease of servicing, the unit must always be mounted on the surface of tiled walls. Never tile up to the unit. Position the unit where it will not be in direct contact with water from the shower head. Mount the shower unit vertically.

  • Page 15: Plumbing

    INSTALLATION Step Step - Temporarily connect the shower to plumbing pipework. - Using the backplate as a template (making sure it is level), mark the fixing holes. Use any 2 holes at the top and any 2 holes at the bottom to secure the shower.

  • Page 16: Electrical

    INSTALLATION Step Step Earth cable (Green/Yellow) to Neutral cable (Blue or Black) to - Route the electrical supply cable into the Live cable (Brown or Red) to shower unit. Note: The supply cable must be secured either Terminal block by routing through conduit, trunking or by embedding in the wall, in accordance with IEE regulations.

  • Page 17: Drain Pump Connectivity

    INSTALLATION Step Step DRAIN PUMP CONNECTIVITY (If no drain pump is being connected to the shower then this step can be ignored) This Omnicare product has been designed to operate with analogue drain pumps only. Configuration 1 for Analogue Drain Pumps When the shower is turned on, a signal is sent to the drain pump electronics telling the pump to start.

  • Page 18: Shower Settings Setup

    INSTALLATION Step Step SHOWER SETTINGS SETUP The Omnicare Ultra shower has some functionality settings that can be customised to individual user’s preference. A DIP switch mounted on the Power PCB allows these settings to be adjusted. Factory Settings Drain Pum Terminal Audible Feedback This function provides an audible notification to specific shower operations and warnings.

  • Page 19: Commissioning

    INSTALLATION COMMISSIONING THE SHOWER Step Step Step Step Attach the appropriate end of the shower Temporarily fit the cover to the shower. hose to the shower outlet, using the DO NOT connect the wire from the cover supplied hose washer seal. DO NOT to shower unit PCB, minor adjustment of overtighten.

  • Page 20: Adjusting The Maximum Temperature Stop

    INSTALLATION Step Step ADJUSTING THE MAXIMUM TEMPERATURE TO 41°C (If not adjusting the maximum temperature then this step can be ignored) The shower unit is supplied factory set to give a nominal maximum temperature of 43°C, however, the temperature selector mechanism can be adjusted to restrict the maximum temperature to 41°C.

  • Page 21: Beab Care

    INSTALLATION Step Step BEAB CARE* MAXIMUM TEMPERATURE (If not adjusting to BEAB Care then this step can be ignored) IMPORTANT: This process should only be performed by a qualified engineer *BEAB care mark specification states a MAXIMUM of 41°C outlet temperature. If the shower is adjusted above the maximum 41°C the product falls outside the BEAB care mark specification.

  • Page 22: Fitting The Cover

    INSTALLATION Step Step Step Step Guide the cover into position so that the temperature selector locates correctly onto the valve (minor adjustment of the Connect the 6-way cable from the cover temperature dial may be necessary to to the socket on the power PCB cable. align with the valve).

  • Page 23: Operating Instructions

    OPERATING INSTRUCTIONS Switch ON the electricity supply at the isolating switch. Check that the power on indicator in the centre of the start/stop button is illuminated with a green light. Start the shower by pressing the Start/Stop button After a few seconds the water will start to flow from the shower head.
  • Page 24 OPERATING INSTRUCTIONS Power On Indicator The power on indicator will Shutdown illuminate with a green light indicator when there is an electricity supply to the shower. Low flow indicator Low Flow Indicator If a low flow condition occurs during showering, the unit Temperature will turn off the water flow control...
  • Page 25 OPERATING INSTRUCTIONS Phased Shutdown In use, every time the Start/Stop button is pressed, power is switched off to the elements. Water will continue to flow for a few seconds, purging any remaining hot water. This makes sure the next immediate user will not receive a slug of hot water if standing under the shower head when starting the shower.

  • Page 26: Maintenance

    MAINTENANCE Instructions for installers and service engineers only INSTRUCTIONS FOR INSTALLERS AND SERVICE ENGINEERS ONLY Instructions for installers and service engineers only Cleaning the Filter It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower. It is essential that this operation is carried out by a competent person.

  • Page 27: Beab Care

    MAINTENANCE - BEAB CARE Important: These tests should only be performed by a qualified engineer. Commissioning and In-Service Tests Commissioning D.1.1 Purpose Since the installed supply conditions are likely to be different from those applied in production it is appropriate, at commissioning, to carry out some simple checks and tests on each instantaneous water heater to provide a performance reference point for future in-service tests.
  • Page 28 MAINTENANCE - BEAB CARE In-service tests D.2.1 Principle The purpose of in-service tests is regularly to monitor and record the performance of the instantaneous water heater. Deterioration in performance can indicate the need for service work on the appliance and/or the water supplies. D.2.2 Procedure D.2.3...
  • Page 29 MAINTENANCE - BEAB CARE Frequency of in-service tests D.3.1 General In-service tests should be carried out with a frequency which identifies a need for service work before an unsafe water temperature can result. In the absence of any other instruction or guidance on the means of determining the appropriate frequency of in-service testing, the following procedure may be used: D.3.1.1 6 to 8 weeks after commissioning, conduct the tests detailed in D.2.2 to D.2.6.

  • Page 30: Fault Finding/Troubleshooting

    FAULT FINDING/TROUBLESHOOTING FAULT FINDING Important: Switch off the electricity at the mains supply and remove the circuit fuse before attempting any fault finding inside the unit. Problem Cause Action Problem/Symptom Cause Action/Cure 1 Shower inoperable, no 1.1 Interrupted power 1.1.1 Blown fuse or circuit breaker.
  • Page 31 FAULT FINDING/TROUBLESHOOTING Problem Cause Action 6 Low flow LED 6.1 Low flow condition. 6.1.1 Insufficient water flow available. permanently ON 1. Check shower head is not blocked. when start/stop is 2. Check shower hose is not restricted. pressed. Shower will 3.

  • Page 32: Alternative User Format Instruction

    Descriptive Word Document Extra Large Print Alternative format User Instructions are available for the this shower and the Remote start/stop button accessory. Should you require a copy of the alternative User Instructions please contact Triton Customer Experience on 024 7637 2222...

  • Page 33: Spares

    SPARES To purchase a genuine Triton spare part for your product, please visit www.tritonshowers.co.uk/spares for product codes and prices. Alternatively please call our Customer Experience team on 024 7637 2222 to order direct. Please have your model name available.
  • Page 36 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2023...
