Triton CAROLI Manual

Bar mixer shower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAROLI
bar mixer
REGISTER ONLINE
ENTER A PRIZE DRAW
WIN
£100
LOVE2SHOP VOUCHERS
VISIT OUR WEBSITE TODAY
TRITONSHOWERS.CO.UK/REGISTER
PRODUCT REGISTRATION IS ONLY AVAILABLE
TO UNITS PURCHASED & INSTALLED IN THE UK
FOR YOUR SERVICE REFERENCE
NOTE DOWN THE PRODUCT CODE BELOW
(FROM THE FRONT OR TOP OF THE BOX)
ALTERNATIVELY REGISTER BY TEL: 024 7637 8321
INSTALLATION AND OPERATING INSTRUCTIONS
Please read this book thoroughly and familiarise yourself with all instructions before commencing
installation and keep it for future reference.
The mixer shower installation MUST be carried out by a suitably qualified person, in the sequence
of this instruction book.
IMPORTANT SAFETY ADVICE
The shower head and hose supplied with
this product are a safety critical part of your
shower. Failure to use genuine Triton parts may
cause injury and invalidate your guarantee.
2181395C - November 2020
86004420

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAROLI and is the answer not in the manual?

Questions and answers

Related Manuals for Triton CAROLI

Summary of Contents for Triton CAROLI

  • Page 1 The shower head and hose supplied with (FROM THE FRONT OR TOP OF THE BOX) this product are a safety critical part of your shower. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. ALTERNATIVELY REGISTER BY TEL: 024 7637 8321...

  • Page 2: Table Of Contents

    GUARANTEE, SERVICE POLICY etc..........rear cover nstallers please note these InstructIons are to be left wIth the user To check the product suitability for commercial and multiple installations, please contact Triton’s speci cation advisory service before installation. Please see back of book for contact information.

  • Page 3: Main Components

    Caroli Bar Mixer Shower MAIN COMPONENTS Fig.1 A. Thermostatic bar mixer valve B. Dogleg connector X2 C. Cover trim X2...

  • Page 4: Dimensions

    Caroli Bar Mixer Shower DIMENSIONS - All dimensions listed in this fitting book regarding Fig.2 the product and installation are approximate.
  • Page 5 Caroli Bar Mixer Shower INTRODUCTION Water Temperature Requirements Recommended maximum: = 65°C This book contains all the necessary fitting and operating instructions for your mixer shower. Minimum hot water temperature: = 55°C Please read them carefully and read through Maximum cold water temperature: = 25°C the whole of this book before beginning your installation.
  • Page 6 Caroli Bar Mixer Shower PLUMBING REQUIREMENTS Hard Water Areas a. If it is intended to operate the shower DO NOT use jointing compounds on any pipe in areas of hard water (above 200-ppm fittings for the installation, temporary hardness), a scale inhibitor DO NOT solder fittings near the mixer shower may have to be fitted.

  • Page 7: Typical Domestic Installations

    Caroli Bar Mixer Shower TYPICAL DOMESTIC INSTALLATIONS *Diagrammatic view – not to scale. *Fig.3 For illustration purpsoes only. Domestic Gravity Fed Systems ( fig.3) The mixer shower MUST be fed from a cold water cistern and hot water cylinder providing nominally equal pressures.
  • Page 8 Caroli Bar Mixer Shower Instantaneous Gas-heated Systems, *Fig.5 *Diagrammatic view – not to scale. e.g. combination boilers (fig.5) For illustration purpsoes only. The mixer shower MUST be installed with a multi-point gas water heater or combination boiler of a fully modulating design i.e. to maintain relatively stable hot water temperatures.
  • Page 9 Caroli Bar Mixer Shower Mains Pressurised Thermal Store Systems *Diagrammatic view – not to scale. *Fig.7 fig.7) For illustration purpsoes only. Packages of this type, fitted with a tempering valve (blender valve) can be used. A drop tight pressure reducing valve MUST be fitted if the supply pressures exceed 5 bar running.

  • Page 10: Installation

    Caroli Bar Mixer Shower INSTALLATION *Diagrammatic view – not to scale. *Fig.8 For illustration purpsoes only. PREPARING THE MIXER SHOWER Check the contents to make sure all items are present. Before starting, make sure all of the openings on the mixer shower are carefully covered to stop ingress of any debris, etc.

  • Page 11: Variable Fittings

    Caroli Bar Mixer Shower *VARIABLE FITTINGS Fig.9 The supply pipes can be routed from the side, rising, rear or falling and must end in suitable fittings to accept the variable connectors (fig.9). The variable connectors can be used to connect Appropriate to ½”...

  • Page 12: Fitting The Shower

    Caroli Bar Mixer Shower FITTING THE SHOWER Fig.11 IMPORTANT: Make sure that all supply pipework has been flushed through before fitting the mixer. Screw the supplied cover trims onto the fittings until tight to the wall (fig.11). Offer the mixer shower up to the fittings.

  • Page 13: Fitting The Shower Controls

    Caroli Bar Mixer Shower FITTING THE SHOWER CONTROLS Fig.12 Maximum The mixer controls will need to be fitted before temperature commissioning can be carried out. stop Temperature Control - (fig 12) Fit the maximum temperature stop on the right had side in the orientation shown.

  • Page 14: Leak Testing

    Caroli Bar Mixer Shower LEAK TESTING THE SHOWER Fig.14 IMPORTANT: Flush out the pipework in accordance with Water Regulations and Bylaws. Fit the hose to the outlet without the shower Mixer outlet head fitted and direct it towards the waste outlet.

  • Page 15: Temperature Adjustment Range

    Caroli Bar Mixer Shower TEMPERATURE ADJUSTMENT RANGE Fig.15 The mixer has a temperature stop to prevent Temperature override accidental rotation to higher temperatures. This button is adjustable to provide a maximum temperature of 35°C – 45°C. The mixed water temperature can be adjusted from cold through to a top limit (which can be pre-set during installation –...

  • Page 16: Operating The Shower

    Caroli Bar Mixer Shower OPERATING THE SHOWER Fig.17 To start the shower, rotate the flow control (left-hand side) anti-clockwise. For maximum flow, rotate the flow control anti-clockwise until it stops. To stop the water flow, rotate the flow control clockwise until the water stops flowing (fig.17).
  • Page 17 Caroli Bar Mixer Shower *SPARE PARTS - bar mixer fittings Ref. Description Part No. A. Bar bracket UNBMXBKT B. Bar bracket (exposed) UNBMXFIXEX C. Bar bracket (push-fit) UNBMXFIXBT D. Straight connector 86001120 The bar mixer fittings can be purchased from Customer Spares.

  • Page 18: Spare Parts

    Caroli Bar Mixer Shower SPARE PARTS PLEASE NOTE: fitting has Left Hand thread Ref. Description Part No. Ref. Description Part No. 1. Knob set........86004450 Flow regulators are available at the following ratings (12.0 L/M supplied): 2. Flow cartridge ......83315530 Flow regulator 3.0 L/M ....

  • Page 19: Tmv2 Requirements (12 Monthly Verification)

    Caroli Bar Mixer Shower TMV2 REQUIREMENTS (12 MONTHLY VERIFICATION) It is a requirement that all TMV2 approved valves shall be verified against the original set temperature results once a year. On installation and on a yearly basis please perform the following checks.

  • Page 20: Maintenance

    Caroli Bar Mixer Shower MAINTENANCE Cleaning It is recommended that all products are cleaned The following maintenance procedure must using warm, soapy water. be carried out for commercial and health care premises, but is not necessarily required for Do not use abrasive or aggressive chemical domestic installations.

  • Page 21: Fault Finding

    Caroli Bar Mixer Shower FAULT FINDING The following can be carried out by a competent person Problem Cause Action 1 Water too hot. 1.1 Temperature 1.1.1 Refer to commissioning section. control incorrectly commissioned. 1.2 Not enough cold 1.2.1 Reposition temperature control knob water flowing through shower.
  • Page 22 Caroli Bar Mixer Shower FAULT FINDING Problem Cause Action 4 Water does 4.1 Water supplies cut off. 4.1.1 Check water elsewhere in house and if not flow or necessary contact local water company. shower pattern 4.2 Shower unit blocked. 4.2.1 Inspect the inlet filters. Clean if necessary.
  • Page 23 Caroli Bar Mixer Shower...
  • Page 24 Trade Installer Hotline: 024 7637 8344 Nuneaton www.tritonshowers.co.uk Warwickshire, CV11 4NR E-mail: serviceenquiries@tritonshowers.co.uk E-mail: technical@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited Triton reserve the right to change product specifi cation without prior notice. E&OE. © TRITON SHOWERS 2020...
