Advanced Setting
FTC Test Mode
30) 30)
FTC Test Mode Active HIGH/Active LOW
The test signal for the safety photocells (FTC/ FTC-S) can be set to operate as "Active HIGH" or "Active
LOW". This can help to match the operating mode of several types of photocells from a range of
manufacturers.
Check the operating mode of the test signal of the safety device used and set the parameter accordingly.
NOTE: If the operating mode doesn't match the door will not move.
Default value = Active HIGH
FTC-S Mode
Advanced Setting
31) 31)
Stop / Reclosing
FTC-S Mode
Set the reaction of the door if an obstacle is detected by the FTC-S sensor during OPENING.
If the safety FTC-S meets an obstacle, the door can react in 2 different ways:
• STOP: the door remains stopped in that position as long as the sensor is activated
• RECLOSING: the door recloses anyway after 4 sec. even if the sensor is triggered
Disabled persons access settings
If the operator is used for disabled persons, adjust the opening and closing speed of the leaf
for Low Energy setting.
Door Length Door Length
750 mm 750 mm
850 mm 850 mm
1 1 000 mm 000 mm
1200 mm 1200 mm
NOTE 1:
According to regulations, when the DISABLED PERSONS ACCESS is activated (See Configuration
Menu):
• The min. Pause Time must be set at 5 Sec.
• The motor torque measured at the main closing edge must be lower then 67 N.
• The min slow time in closing must be 1.5 sec.
These values can be set in the Main Functions menu.
NOTE 2:
When the Disabled Persons Mode is enabled, if the door is open through a C-NO command on
inputs 15-16, it will reclose after the Pause Time Extended. If the command comes from inputs
(radar, push&go, remote control), the Pause time remains the regular one. The Pause Time
extended is always executed if the open command comes from button D of a remote control.
Warning: disabled person access doors must be identified Warning: disabled person access doors must be identified
with proper signage. with proper signage.
32
Door weight Door weight
50 Kg 50 Kg 60 Kg 60 Kg 70 Kg 70 Kg 80 Kg 80 Kg 90 Kg 90 Kg
3.0 s 3.0 s 3.1 s 3.1 s 3.2 s 3.2 s 3.3 s 3.3 s 3.5 s 3.5 s
3.1 s 3.1 s 3.1 s 3.1 s 3.2 s 3.2 s 3.4 s 3.4 s 3.6 s 3.6 s
3.2 s 3.2 s 3.4 s 3.4 s 3.7 s 3.7 s 4.0 s 4.0 s 4.2 s 4.2 s
3.8 s 3.8 s 4.2 s 4.2 s 4.5 s 4.5 s 4.8 s 4.8 s 5.1 s 5.1 s
EN EN
Fully automated operator for inward or outward opening doors

Remote controls management

The unit is equipped with a superhetherodyne AM receiver with KeeLoq® hopping code security
protocol. In the TX Management menu you can manage the memory of the receiver, which can
store up to 50 transmitters.
The system manages 2 types of transmitters : Master and regular.
• The transmitter Master allows you to enter the menu and change the settings. Only ONE
Master transmitter can be memorised. There is a special option for memorising a Master
transmitter. A new Master transmitter will overwrite the old one.
• The regular transmitters can only trigger the system by giving the opening command.
MENU MAIN Tx Management
Tx Management ADD Master
Press TX Button
to ADD
Tx Management
ADD
Appuyer bouton
TX pour ajouter
Tx Management
REMOVE
Press TX Button
to REMOVE
Tx Management
REMOVE ALL
REMOVE ALL TX
from DATABASE?
Tx Management
LIST
SN 00001234 ABCD
Press OK to REMOVE
Confirm remove?
Press OK or ESC
DIGIWAY PLUS
To add a transmitter to the memory, select ADD from the TX To add a transmitter to the memory, select ADD from the TX
MANAGEMENT menu and press OK. At the message "PRESS MANAGEMENT menu and press OK. At the message "PRESS
TX BUTTON to ADD", press the button of the transmitter to TX BUTTON to ADD", press the button of the transmitter to
memorise it. If everything is correct the Serial Number of the memorise it. If everything is correct the Serial Number of the
transmitter will appear on the LCD display. If the transmitter transmitter will appear on the LCD display. If the transmitter
is already present in the memory, the following message will is already present in the memory, the following message will
appear: TX ALREADY PRESENT. appear: TX ALREADY PRESENT.
To delete a transmitter select the option To delete a transmitter select the option REMOVE
the TX MANAGEMENT menu and press OK. At the message the TX MANAGEMENT menu and press OK. At the message
"PRESS TX BUTTON to REMOVE", press the button on the "PRESS TX BUTTON to REMOVE", press the button on the
transmitter to delete. If everything is correct, the message: transmitter to delete. If everything is correct, the message:
TX REMOVED will appear on the LCD display. TX REMOVED will appear on the LCD display.
To delete the first transmitter you only need to press one To delete the first transmitter you only need to press one
button. button.
To delete any other transmitter you need to delete each To delete any other transmitter you need to delete each
button individually. button individually.
To To completely completely erase the database select the option erase the database select the option REMOVE
ALL ALL from the TX MANAGEMENT menu and confirm. At the from the TX MANAGEMENT menu and confirm. At the
message "REMOVE ALL TX from DATABASE menu, press OK message "REMOVE ALL TX from DATABASE menu, press OK
and the memory will be completely erased. and the memory will be completely erased.
ATTENTION : This action also removes the Master transmitter. ATTENTION : This action also removes the Master transmitter.
Navigation will only be possible with the keyboard buttons or after Navigation will only be possible with the keyboard buttons or after
memorisation of a new Master transmitter. memorisation of a new Master transmitter.
For each transmitter the system displays the serial number For each transmitter the system displays the serial number
and the buttons memorised. The Master transmitter always and the buttons memorised. The Master transmitter always
has all 4 buttons memorised (A, B, C, D). has all 4 buttons memorised (A, B, C, D).
For the regular transmitters the letters show the active For the regular transmitters the letters show the active
buttons. buttons.
Press OK to delete the transmitter, UP or DOWN to scroll the Press OK to delete the transmitter, UP or DOWN to scroll the
list, ESC to return to the upper menu. list, ESC to return to the upper menu.
Use this option to check the transmitters memorised or to Use this option to check the transmitters memorised or to
delete a lost transmitter. delete a lost transmitter.
REMOVE from from
REMOVE
