DIGIWAY PLUS
Fully automated operator for inward or outward opening doors
Electronic card specifications Electronic card specifications
Operating modes: Automatic ( I ) - Door free ( 0 ) - Door always open (II) Operating modes: Automatic ( I ) - Door free ( 0 ) - Door always open (II)
Inputs: Inputs: Re-open photocells (NC) Re-open photocells (NC)
Stop photocells (NC) Stop photocells (NC)
Door always open (NO) Door always open (NO)
Door free (NO) Door free (NO)
External Radar (NO) External Radar (NO)
Internal Radar (NO) Internal Radar (NO)
Day / Night selection (NO) Day / Night selection (NO)
Open / Close command (NO) Open / Close command (NO)
Fire alarm voltage (+V, -V) [optoisolated] Fire alarm voltage (+V, -V) [optoisolated]
Outputs: Outputs: Door open contact (C-NO) Door open contact (C-NO)
External devices power 13.5 Vdc / 500 mA External devices power 13.5 Vdc / 500 mA
Electrolock output contacts (C-NO-NC) Electrolock output contacts (C-NO-NC)
Electrolock power 12 Vdc / 1 A Electrolock power 12 Vdc / 1 A
Test for safety devices (FTC- FTC-S) Test for safety devices (FTC- FTC-S)
Main features Main features
• • Operating modes: Fully automatic, Door open, Door free/operation off; Operating modes: Fully automatic, Door open, Door free/operation off;
• • Operating with single door, double door, with or without leaf overlapping; Operating with single door, double door, with or without leaf overlapping;
• • Guided procedure for quick basic setup; Guided procedure for quick basic setup;
• • Adjustable motor torque during open and close phases; Adjustable motor torque during open and close phases;
• • Remote controls management, master transmitter and user transmitter; Remote controls management, master transmitter and user transmitter;
• • Auto slow down during approach to door limits; Auto slow down during approach to door limits;
• • Push & Go / Pull & Go function; Push & Go / Pull & Go function;
• • Pause Time, Max Speed, Torque and Velocity adjustable; Pause Time, Max Speed, Torque and Velocity adjustable;
• • Opening Jolt fully adjustable; Opening Jolt fully adjustable;
• • Two-colour status LED; Two-colour status LED;
• • Electrolock hold time and torque adjustable; Electrolock hold time and torque adjustable;
• • Opening Jolt parameters adjustable; Opening Jolt parameters adjustable;
• • Spring mode (Door always free, spring simulation with auto closing); Spring mode (Door always free, spring simulation with auto closing);
• • Stop and reopen photocell inputs; Stop and reopen photocell inputs;
• • "Fire mode"; "Fire mode";
• • Night / day mode; Night / day mode;
• • Door open output relay (gives open volt free contact whilst door is open). Door open output relay (gives open volt free contact whilst door is open).
• • Secure mode protected by a password Secure mode protected by a password
• • Parametrised inputs for optional limit switch of door closed Parametrised inputs for optional limit switch of door closed
10
EN EN
Fully automated operator for inward or outward opening doors

2] INSTALLATION

Important: Check the integrity of the door that is to be automated, verifiying the Important: Check the integrity of the door that is to be automated, verifiying the
operation in both directions is smooth without any friction from the closed to open operation in both directions is smooth without any friction from the closed to open
position and the open to closed position. If this is not the case, make any repairs position and the open to closed position. If this is not the case, make any repairs
or improvements necessary to achieve smooth operation of the door. Remove any or improvements necessary to achieve smooth operation of the door. Remove any
manually operated locking mechanism unless it is to be used with a strike. A door manually operated locking mechanism unless it is to be used with a strike. A door
stop is not required to complete the opening cycle. stop is not required to complete the opening cycle.
Warning: Any existing closing device should be removed to allow the door to move freely. Warning:
Any existing closing device should be removed to allow the door to move freely.
Hydraulic devices MUST be replaced with dummy units as adjusting the device will not allow Hydraulic devices MUST be replaced with dummy units as adjusting the device will not allow
the DIGIWAY to operate correctly. the DIGIWAY to operate correctly.
Mechanical installation: sliding arm version
The Sliding Arm is designed for pull applications and inward opening doors. The Sliding Arm is designed for pull applications and inward opening doors.
Thanks to the universal arm kit, the main lever of the articulated arm can also be used for a
sliding arm configuration.
C
Value
Parameter
(mm)
A A 280 280 Door hinge – motor axis distance Door hinge – motor axis distance
B B 35 35 Backplate – guide distance Backplate – guide distance
C C 70.5 70.5 Motor axis - vertical plate distance Motor axis - vertical plate distance
DIGIWAY PLUS
B
A
Description
Important: The door face Important: The door face
and DIGIWAY mounting must and DIGIWAY mounting must
be in line as shown above. be in line as shown above.
