INSTALLATION MANUAL
DIGIWAY PLUS
If the operator is used for disabled persons access, adjust the opening and closing speed of the leaf for Low Energy setting
NOTE1 : According to the Regulation, when activated the DISABLED PERSONS ACCESS [See configuration Menu]:
• The min. Pause Time must be set at 5 Sec.
• The motor torque measured at the main closing edge must be lower then 67 N.
• The min slow time time in closing must be 1,5 sec.
Manage to set these values acting on the menu Main Functions.
NOTE2 : When the Disabled Persons Mode is enabled, if the door is open throught a C-NO command on inputs 15-16, it will reclose
after the Pause Time Extended. If the command comes from inputs ( radar, push&go, remote control ), the Pause time remains the
regular one. The Pause Time extended is executed always if the open command comes from the button D of a remote control
Warning : Disabled person access doors must be identified with proper indications.
The unit is equipped with a superhetherodyne AM receiver with Keeloq® Hopping code security protocol.
Through the menu TX Management it is possible to manage the memory of the receiver which can store up to 50 transmitters.
MENU MAIN
Tx Management

Disabled persons access settings

Door lenght
750 mm
850 mm
1000 mm
1200 mm

remote controls management

To memorize a transmitter, select ADD from the menu TX MANAGEMENT and
Tx Management
press OK. At the message "PRESS TX BUTTON to ADD", press the button of
ADD
the transmitter to memorize it . If everything is correct the Serial Number of the
transmitter will appear on the LCD display. If the transmitter is already present in the
Press TX Button
memory, the following message will appear: TX ALREADY PRESENT.
to ADD
To delete a transmitter select the option REMOVE from the menu TX MANAGEMENT
Tx Management
REMOVE and press OK. At the message "PRESS TX BUTTON to REMOVE, press the button
of the transmitter to cancel. If everything is correct, the message: TX REMOVED will
appear on the LCD display.
Press TX Button
To delete the first transmitter it's enough to press one button.
to REMOVE
To delete any other transmitter you need to delete each button individually.
To erase completely the data base select the option REMOVE ALL from the menu TX
Tx Management
MANAGEMENT and confirm. At the message "REMOVE ALL TX from DATABASE,
REMOVE ALL
press OK and the memory will be completely erased.
REMOVE ALL TX
from DATABASE?
Door weight
50 Kg 60 Kg 70 Kg
3,0 s 3,1 s 3,2 s
3,1 s 3,1 s 3,2 s
3,2 s 3,4 s 3,7 s
3,8 s 4,2 s 4,5 s
ATTENTION : This action also removes even the 4-ch transmitter, used to
navigate through the menu. The navigation will be possible only with the
buttons of the keyboard or after the memorization of a new 4-ch transmitter,
in the first memory location.
80 Kg 90 Kg
3,3 s 3,5 s
3,4 s 3,6 s
4,0 s 4,2 s
4,8 s 5,1 s
