DIGIWAY PLUS
Fully automated operator for inward or outward opening doors
Legend Display in Expert Mode Legend Display in Expert Mode
M / S M / S o o O O c c C C B B 1,2,3,4,5,f 1,2,3,4,5,f
Master / Master /
Opening Opening Open Open Closing Closing Closed Closed Obstacle Obstacle
Slave Slave
FMoOcCBXbsMiIUJ
P=-000.0 V=-00.0
Action in progress Action in progress
F F Forward Forward
R R Reverse Reverse
Position (+/-) Position (+/-)
K K Brake Brake
I I Idle Idle
Reset to Factory Defaults
If the setup of the parameters hasn't been successful, you can recover the factory settings using
the sub-menu FACTORY DEFAULTS from the Main Menu. After the completion of this function,
all the parameters will be reset to factory values. See each function to find the corresponding
value.
Menu Main Reset to Factory
Factory Defaults Defaults?
Are you sure?
Having reset the system to the factory settings, the engineer can operate the door but without
using the acceleration and deceleration values calculated during the Step III of Door Calibration.
In order to revert to the previous operating mode you need to repeat Step III again.
The door limits (DOOR CLOSE and DOOR OPEN) remain the same. The transmitter memory
is completely erased, Master transmitter included, and the System password for the partial
counter is reset to 1111.
System Reset
It is possible to reset the system, equivalent to a "power-off + power-on", using the option
"System Reset" from the Main Menu. After the system reset the LCD displays the software
release, the condition of the parameters and the free memory space for transmitters. This
function doesn't change the value of any parameter except for the currents (I and i) which will
be re-calculated during the next 2 cycles.
MENU MAIN Confirm
System Reset System Reset?
Are you sure?
36
b b s s M M i i I I
Restart for Restart for Opening Opening Closing Closing
Obstacle Type Obstacle Type Stop Stop Motor Motor
obstacle obstacle Current Current Current Current
Speed: rpm/10 Speed: rpm/10
P P V V
Answer OK to proceed or ESC to exit without any action.
EN EN
Fully automated operator for inward or outward opening doors

4] DOUBLE DOOR CONFIGURATION

U U J/E J/E
The double door configuration applies to both types DWPD102X (not available in the UK) and
Electrolock Electrolock Opening Jolt Opening Jolt
DWPS102X.
For types DWPD, for which a central profile is provided, it is necessary to install a back plate
which ensures perfect alignment between the profiles and 2 lateral backplates in place of the
regular single door backplate. Follow the instructions below for the mechanical fixing of the
structure (Part I: mechanical fixing).
In case of 2 single standard operators (type DWPS102X) to drive a double door, make the
mechanical fixing by following the regular procedure for each single door.
• • PART I : Mechanical fixing PART I : Mechanical fixing
• • PART PART II : Electrical connections II : Electrical connections
• • PART PART III : Final Setup III : Final Setup
Part I: Mechanical fixing
1. Backplate fixing
• Locate the best position for the central backplate, matching the centre of the plate with the
centre of the double door;
• Mark the position of the holes for the plugs provided;
• Make the holes and insert the plugs provided;
• Pass the power supply cable through the central hole of the backplate;
• Fix the central backplate by using the screws and the plugs provided, ensuring it is perfectly
levelled.
• Align the side backplates on each side and locate the position of the oval holes.
• Make the holes and insert the plugs.
• Fix the side backplates with the screws provided.
2. Central profile fixing
Fix the back central profile with the side caps with the 4 M6x14 screws provided on the central
backplate.
