DIGIWAY PLUS
Fully automated operator for inward or outward opening doors

PART I: CONFIGURATION

The CONFIGURATION submenu allows you to set up of all the basic parameters of the operator
depending on the door type that is being automated. It consists of 18 parameters. Each
parameter can have 2 or more values. For each parameter there is a preset factory value. If
the FACTORY DEFAULT function of the main menu is activated, all the parameters are reset to
those values.
All paramaters are described in the table below:
Parameter Description
Number of Doors Sets the number of doors
Electrolock Enables the electrolock and specifies the type
Enables the Opening Jolt: SHORT CLOSING PULSE BEFORE
Opening Jolt
OPENING, useful when using an electric strike to stop binding.
Push & Open Opens the door automatically with a short push.
Push & Close Closes the door with a short push even in pause status.
Keeps the door closed in presence of wind which pushes the
Wind Stop
door. See ADVANCED SETTINGS to set the level of the
closing force used.
Autoreclosing Enables the automatic reclosing of the door.
INTERNAL radar operating mode. If the CLOSING option is
Radar 'I' Mode selected, the radar is excluded during the closing cycle. This
prevents the door reopening if the arm or door is detected. (*)
EXTERNAL radar operating mode. If the CLOSING option is
Radar 'E' Mode selected, the radar is excluded during the closing cycle. This
prevents the door reopening if the arm or door is detected. (*)
Disable the radar in night mode (contact closed on terminals
Day / Night 14-15) - In NIGHT MODE the External radar or both
radars are disabled.
Disabled access mode (see paragraph: Disabled Access
Disabled Mode
settings)
Optional functions for the open command; Open, Close or
Open Command Stop. Once selected the function will operate from the open
button (terminals 15 - 16) and the radio transmitter.
If the door is closed it will remain free and can be pushed/
pulled manually; if opened fully it will close after the preset
Sprin Mode
pause time.
Note: If the door is partially opened up to 75% the pause
time will be 1 sec and will close after.
Overlap of the leaves (in case of double doors). The MASTER
2 Doors Overlap leaf starts opening first, the SLAVE starts closing first. If
disabled the doors open simultaneously
Door Type MASTER leaf or SLAVE leaf (in case of double doors)
Articulated or sliding arm. This parameter sets the VELOCITY
of the door according to the arm type selected. (see
Arm Type
Adjustments)
50% ARTICULATED ARM, 70% SLIDING ARM
Fire signal management. When this option is enabled the
door operates normally if the fire voltage is present V+/V-.
Fire Signal
If the fire power is removed (fire alarm triggered) the door
reacts to the option set in the advanced settings.
ATTENTION: Any change carried out requires a complete cycle (open, pause, close) or a system ATTENTION: Any change carried out requires a complete cycle (open, pause, close) or a system
reset to be implemented. reset to be implemented.
22
EN
Option Default
1 DOOR / 2 DOORS 1 DOOR
NO LOCK / STRIKE/
NO LOCK
MAGLOCK
ENABLE / DISABLE DISABLE
ENABLE / DISABLE ENABLE
ENABLE / DISABLE ENABLE
ENABLE / DISABLE DISABLE
ENABLE / DISABLE ENABLE
NEVER / CLOSING /
NEVER
ALWAYS
NEVER / CLOSING /
NEVER
ALWAYS
E Radar OFF /
E Radar OFF
I+E radar OFF
ENABLE / DISABLE DISABLE
OPEN - OPEN / CLOSE - OPEN /
OPEN-CLOSE / STOP CLOSE
ENABLE / DISABLE DISABLE
ENABLE / DISABLE DISABLE
MASTER / SLAVE MASTER
SLIDING / ARTICULATED SLIDING
ENABLE / DISABLE DISABLE
EN
Fully automated operator for inward or outward opening doors
PART II: DOOR CALIBRATION
DIGIWAY Plus has an innovative software which adapts the internal paremeters to the
characteristics of the door. The calibration sets the door travel limits and launches a 5-cycle
routine for the automatic detection of door characteristics.
Follow the steps below for the door calibration procedure:
NOTE: Before proceeding with the calibration check the connection of the battery's red/black
cable to the main board and temporarily disconnect any lock if connected. Make sure any door
latch is retracted to allow clear operation of the door movement.
Action Action
Set the external switch in position 0
1 1
(*) If this set is not followed, the software will give a warning.
'0' = DOOR FREE (*)
Select Door Calibration from the Main
2 2
Menu and press OK
Select Door Limits from the submenu
3 3
of Door Calibration and press OK
Close the door FULLY and press OK
4 4
5 5 Open the door FULLY and press OK
(*)
6 6 Select Autocalibration from the Door
Calibration Menu and press OK
7 7
Press OK: the door begins 5 cycles of
opening and closing until asking to
SAVE
8 8
Press OK. The calibration cycle is
over. The door remains open.
Set the external switch to position 'I'
9 9
= AUTOMATIC. The door closes and
the calibration is completed.
DIGIWAY PLUS
Display Display
Door Calibration
Door Calibration
Door Limits
Close Door
Then Press OK
Open Door
Then Press OK
Door Calibration
Autocalibration
Proceed with
Autocalibration?
Closing...
Measure 1/5...
Tm= XX,X V= XX
Save ?
Warning: whilst the door
operator is going trough its
5 learning cycles, it can be
dangerous to pass through
the door as it opens very
....C........................... quickly.
P=000,0 V=00,0
