DIGIWAY PLUS
Fully automated operator for inward or outward opening doors
1] IDENTIFYING THE PRODUCT AND ITS PARTS
DIGIWAY type DWPx102xx is an indoor operator for swing doors, with integrated electronic
controller and radio receiver. The opening and closing motion is electromechanical with backup
battery, which assures operation in cases of power failure.
The following versions are available:
Code F Reference
F0543000093 F0543000093 DWPS102SCD DIGIWAY PLUS operator 230VAC for inswing doors - sliding arm DIGIWAY PLUS operator 230VAC for inswing doors - sliding arm
F0543000094 F0543000094 DWPS102ACD DIGIWAY PLUS operator 230VAC for outswing doors - articulated arm DIGIWAY PLUS operator 230VAC for outswing doors - articulated arm
F0543000095 DWPS102UCD DIGIWAY PLUS operator 230VAC for inswing or outswing doors - universal DIGIWAY PLUS operator 230VAC for inswing or outswing doors - universal
arm arm
F0543000180 DWPS102ABT DIGIWAY PLUS operator 230VAC for inswing doors - articulated arm
w/ Bluetooth module
F0543000181 DWPS102SBT DIGIWAY PLUS operator 230VAC for outswing doors - sliding arm
w/ Bluetooth module
F0543000182 DWPS102UBT DIGIWAY PLUS operator 230VAC for inswing or outswing doors - universal
arm - w/ Bluetooth module
The operator is suitable for swing doors with max width of 1.2 m or max weight of 120kg
(refer to diagram on page 7). At max speed the door can open and close within 3 sec. (90°),
depending on door weight and dimensions.
See the technical specifications in the following pages of this manual.
Warning: Warning: The operator is suitable only for top-jamb fixing. Door leaf The operator is suitable only for top-jamb fixing. Door leaf
fixing is not allowed. fixing is not allowed.
2
1
3 4 5 6 7
11 12
10
6
Description
Legend Legend
1 - Anodised aluminium cover 1 - Anodised aluminium cover
2 - Motor shaft 2 - Motor shaft
3 - Status led LP 3 - Status led LP
4 - Receiver card 4 - Receiver card
5 - Display LCD 5 - Display LCD
8 9
6 - 5-button keyboard 6 - 5-button keyboard
7 - Gear box 7 - Gear box
8 - Motoriductor 8 - Motoriductor
9 - Encoder 9 - Encoder
10 - Slot for cover opening 10 - Slot for cover opening
11 - Toroidal transformer 11 - Toroidal transformer
12 - Backup battery 12 - Backup battery
13 - Battery cable with 13 - Battery cable with
13 14 15
protection fuse protection fuse
14 - Jumper for external 14 - Jumper for external
selector exclusion selector exclusion
15 - Operating mode 15 - Operating mode
selector selector
EN EN
Fully automated operator for inward or outward opening doors

Accessories

Description P/N
Articulated
arm short tube DWAA35
extenstion
Articulated Articulated
arm long tube arm long tube DWAA55
extenstion extenstion
Tube extension Tube extension
DWAA55E
only only
Universal arm kit DWSRKU Universal arm kit
Extension shaft Extension shaft
DWSE
55 mm 55 mm
Extension shaft Extension shaft
DWSE30
30 mm 30 mm
Extension shaft Extension shaft
DWSE80
80 mm 80 mm
Double door Double door
DWPCS
cable cable
Mounting tools Mounting tools
DWTK
kit kit
Bluetooth plug-in Bluetooth plug-in
DWMBT
module (*) module (*)
(*): The models with the suffix BT (refer to table on pg 6), come with the Bluetooth module built-in. The (*): The models with the suffix BT (refer to table on pg 6), come with the Bluetooth module built-in. The
models with the suffix CD on the part name can also be equipped with the Bluetooth module. See page models with the suffix CD on the part name can also be equipped with the Bluetooth module. See page
43 for details concerning after-sale installation of the module, for its configuration and use. 43 for details concerning after-sale installation of the module, for its configuration and use.
