5. COMMUNICATION

5.1 RS232 and USB

3.
4.
5.2 UPS remote control
Remote Power Off (RPO)
When RPO is activated, UPS will cut off output immediately, and
continues to alarm.
RPO
Connector type
External breaker specification
Dry in
Dry in function can be configured (see Settings > Dry in)
DRY IN
Connector type
External breaker specification
Dry out
Communication cable to the serial or USB port on the
computer.
Connect the other end of the communication cable to the
RS232 or USB communication port on the UPS.
functions
COMMENTS
16 AWG Maximum wires
60 V DC/30 V AC 20 mA max
COMMENTS
16 AWG Maximum wires
60 V DC/30 V AC 20 mA max
