Install the unit
Always keep 200 mm of free space behind the UPS rear panel.
Check that the indications on the name plate located on the top
cover of the UPS meets to the AC-power source and the true
electrical consumption of the total load.
Note: The UPS charges the battery as soon as it is connected to
the AC-power source, even if button is not pressed.
Once the UPS is connected to the AC-power source, 8 hours of
charging are required before the battery can supply the rated
backup time.
61
1-Connect the UPS
input socket to the
AC-power source
using the cable of
the protected
equipment.
2-Connect the loads
to the UPS using the
cables.
