General

A7000 series locks
installation dimensions and can be installed
in all 4 installation positions (right, left, top,
bottom). They are designed for "scissor-
bolt" movements, i.e. for force absorption
by the bolt flanks.
They are intended to be installed in metal
safes.
Depending on the version, additional
locking elements (e.g. angle rail with bolts)
can optionally be attached to the bolt using
the existing holes. Ensure the proper
operation of the lock and its connection.
The electronic lock is maintenance-free in a
normal residential or office environment.
After approximately 10,000 closures, it is
recommended to have a security and
functional check of the electronic lock
conducted by a safe technician.
02 A7000-Part 2b-Installation Manual V1.04
have standard No not allow the opening for the keyhole to
exceed a rectangle measuring 27 x 9 mm.
It is essential that the lock is protected
against external attacks. We recommend
protecting the
components of the high-security lock from
being accessed even when the safe door is
open.
Do not apply any lubricants or other
substances to the lock.
Multiple locks where the closure needs to
be checked by a bolt movement, as is the
case with the A-7000, may not be installed
on the boltwork of a safe. If the lock on a
boltwork is combined with locks featuring a
closing status indicator, then the A-7000
must first be closed and the closure status
checked.
security-relevant
