Anchor 7000
Installation Manual
Installation and Commissioning Manual
Preparation of the boltwork / door
To install the lock, there needs to be three
threaded fixing holes on the boltwork or
inside the safe door. Use the screws
supplied or M6 of 1/4" cylinder screws (min.
Installation
Tighten the retaining screws to ensure a
permanent and firm hold.
Tighten the fastening screws with a
maximum torque of 3.5 - 5 Nm.
Cabling / installation
Cabling
Fundamentally, the installation positions of
the input unit and lock can be sited
independently of each other.
openings with a diameter of 9 mm through
which to pass the cables into the safe.
02 A7000-Part 2b-Installation Manual V1.04
strength class 8.8) to fix the electronic lock.
Measure the length of the screws to ensure
a minimum screw penetration depth of 5
mm.
We recommend using a bolt locking agent
(adhesive) to prevent the screws from
coming undone by themselves.
Ensure that the bolt of the lock is not under
tension or pressure once installed.
Make sure there is sufficient clearance to
the locking point.
Particularly when using series FS keypads,
it is possible to install them centred to the
Make
keyhole. The keypad flap thus also acts as
a cover for the keyhole.
Possible drilling positions for this case are
shown in Figure 2.
4 / 10
