Anchor / Primor
Installer manual input unit
Installation and commissioning instructions

General

In principle, all locks in these series can be
operated with input units from the Primor
and Anchor series.
For direct drive lock versions whre the bolt
drive is done via an external axis, rotatable
input units or with actuating knobs are
available.
In combination with e.g. locks with a motor-
driven bolt, these can also be used as a bolt
work drive, depending on the application.
Always use the following sequence for installation:
•Check the preconditions for installation
•Preparing for installation: Drill the fastening holes and door hole (spindle/axis)
•Wiring / installation of the cables
•Function test
02 en_APxxx-Teil 2a-Errichterhandbuch Tastatur V2.05.docx
Also conceivable is the bolt drive via a
separate handle or rotary knob operated via
one of the fixed keyboards. If the wiring
connection is not routed through the drive
axle, the required wiring route must be
selected in such a way that tools, probes,
etc. cannot access the lock body through it.
Holes for the cable outlet must be at least
8mm and may not exceed a maximum of
11.4mm.
