Appendixes


This document is preliminary and subject to change.
The document contains the following appendixes:
•

Accessory and Replacement Parts

• Thermal Threshold Definitions
• Interface Specifications
• Disassembly and Disposal
Accessory and Replacement Parts
Ordering Part Numbers for Replacement Parts
Part Type Part Number
Rack 930-9NRKT-00JN
Installation -000
Kits
930-9BRKT-00JJ-
000
930-9NRKT-00JE
-000
930-9NRKT-00JV
-000
Power 930-9NPSU-00J1
Supply -000
Units
930-9NPSU-00JI-
000
930-9BPSU-00JZ
-000
930-9BPSU-00JG
-000
Fan 930-9BFAN-00IN-
Modules 000
930-9BFAN-00J0-
000
Cables and HAR000631
Harnesses
ACC001310
Legacy Part Description
Number
MTEF-KIT-J NVIDIA 19" racks fixed mounting-kit,
Standard-depth, Rack size 600-800mm
MTEF-KIT-F Rack installation kit for 200G 1U systems
to be mounted into short/standard
depth racks
MTEF-KIT-BP NVIDIA 19" racks fixed mounting-kit, for
SN2410, SN3420 systems, Short-depth,
Rack size 500-600mm
MTEF-KIT-SP NVIDIA 19" racks fixed mounting-kit, for
SN2410, SN3420 systems, Short-depth,
Rack size 600-800mm
MTEF-PSF- Power-Supply Unit, 550W AC, P2C
AC-E Airflow, Power cord included
MTEF-PSR- Power-Supply Unit, 550W AC, C2P
AC-E Airflow, Power cord included
MTEF-PSF- Power-Supply Unit, 1100W AC, P2C
AC-C Airflow, Power cord included
MTEF-PSR- Power-Supply Unit, 1100W AC, C2P
AC-C Airflow, Power cord included
MTEF-FANF-C 200G 1U systems FAN MODULE W/ P2C
air flow
MTEF-FANR-C 200G 1U systems FAN MODULE W/ C2P
air flow
N/A RS232 Cable - DB9 to RJ45 2M harness
2M for SX67X0 and SB78X0
N/A Power cord black 250v 10a 1830mm c14
to c13 - Master power cord
Supported Systems
SN3700/SN3700C
SN3700/SN3700C
SN3420
SN3420
SN3420
SN3420
SN3700/SN3700Cf
SN3700/SN3700C
SN3700/
SN3700C, SN3420
SN3700/
SN3700C, SN3420
SN3700/SN3700C,
SN3420
SN3700/SN3700C,
SN3420
73
