Connector Pin Number
31
32
33
34
35
36
37
38
Adapter Dimensions
SFP28
Rear View of Module with Pin Placement
Symbol
LPMode
GND
Tx3p
Tx3n
GND
Tx1p
Tx1n
GND
Signal Description
Low Power Mode
Ground
Connected to Port 3 lane Rx
Non-Inverted Data
Connected to Port 3 lane Rx
Inverted Data
Ground
Connected to Port 1 lane Rx
Non-Inverted Data
Connected to Port 1 lane Rx
Inverted Data
Ground
76
