  • Page 1 SN3420 Ethernet Switch Systems Quick Installation Guide...
  • Page 2 Table of contents Table of contents Installation and Configuration Installation and Configuration SN3420 Ethernet Switch Systems Quick Installation Guide...

  • Page 3: Pay Attention

    1 x Harness RS232 2M cable – DB9 to RJ-451 2 x Power cables – Type C13-C14 2 x Cable retainers Quantity Item X8 (of each) B, C X2 (of each) D, E SN3420 Ethernet Switch Systems Quick Installation Guide...
  • Page 4 Quantity Item If anything is damaged or missing, contact your NVIDIA representative at Networking- support@nvidia.com. SN3420 Ethernet Switch Systems Quick Installation Guide...

  • Page 5: Installation And Configuration

    Installation and Configuration Installation Instructions Illustration Do not tighten the screws yet. SN3420 Ethernet Switch Systems Quick Installation Guide...

  • Page 6: System Interfaces

    Connector (Front) Side FRU (Rear) Side * It may take up to five minutes to turn on the system. If the System Status LED shows amber after five minutes, unplug the system and contact your NVIDIA representative. LED Assignments Symbol...
  • Page 7 1. Connect the host PC to the Console (RJ-45) port. 2. Configure a serial terminal program. Parameter Settings Baud rate 115200 Data bits Stop bits Parity None Flow control None 3. Login: Username Password Onyx (MLNX-OS) admin admin ONIE SN3420 Ethernet Switch Systems Quick Installation Guide...
  • Page 8 MAC of the switch with your DHCP server (MAC can be found on switch label) or using "ifconfig eth0" (when using MGMT0). For further information, refer to: https://docs.cumulusnetworks.com/display/DOCS/Quick+Start+Guide For full installation instructions, go to https://docs.nvidia.com/networking/category/switchen. © Copyright 2024, NVIDIA. PDF Generated on 08/14/2024 SN3420 Ethernet Switch Systems Quick Installation Guide...
