1.
Turn off the system and disconnect it from peripherals and from the electrical outlet.
2.
Unscrew the two M6 screws securing the front of the inner rails' ears to the outer rails and to
the rack.
3.
Pull the unit out until braking is felt. For safety purposes, the locking mechanism will not
allow a complete removal of the unit at this stage.
Pulling the Unit Outwards
4.
Press on the locking spring (appears in red in the figure below) on both sides simultaneously,
and continue pulling the unit towards you until it is fully removed.
Locking Mechanism
SN3750-SX Tool-less Rail Kit
Kit Part Number
930-9BRKT-00JM-000
Legacy Kit Part Number
MTEF-KIT-I-TL
Rack Size and Rack Depth Range
600-800 mm
25
