The Tester

6.1

Functions Description

Qualified electricians can use the device to test AC charging points for correct func-
tioning. In addition to cable and vehicle simulation, faults can also be simulated and
communication can be evaluated to this end.
Beyond this, AC charging points can be electrically tested by combining the tester
with a measuring/test instrument from the PROFITEST MF or PROFITEST MASTER
IQ series for the purpose of initial testing in accordance with DIN VDE 0100-600
and for periodic testing during operation in accordance with DIN VDE 0105-100.
6.2

Device Characteristics

• The tester can only be used to test AC charging points in charging mode 3.
• Vehicle simulation (CP): the tester simulates the charging socket of the electric
vehicle. It can be connected to the charging socket or the type 2 plug of an AC
charging point.
• Cable simulation (PP): the tester uses an automatic program sequence to check
values for a 13, 20, 32 or 63 A cable. Testing for the absence of a connected
cable is also possible (N.C.).
• Communication (PWM signal) can be evaluated.
• Fault simulation: the tester can be used to perform diode testing, as well as to
check for CP-PE short-circuits (fault E) and PE faults (ground faults).
• In combination with instruments from the PROFITEST MF or PROFITEST MAS-
TER IQ series, protective devices at AC charging points can be tested:
– Continuity of the conductors (low-resistance measurement)
– Insulation resistance
– Testing of residual current circuit breakers (RCD/R)
– Sensor testing, 6 mA RDC-DD/RCMB
– Fault loop impedance (loop resistance), internal system resistance
6.3

Scope of Delivery

Please check for completeness.
1 PROFITEST H+E EXPERT CHECK (M525R)
1 Charging cable (micro USB plug)
1 Operating instructions (this document)
