Instructions for Behnke Hybrid series 20-0005-BS, SIP intercoms series 20-0005B-IP

BasIc ElEctronIcs

3.
(Electronics box for 20-0005-BS, 20-0005B-IP)
a/b port
twisted pair of wires
Configuration key
Status LED
The connection of the
earth is required if it
is a TNV-1/ES1 circuit,
e.g. if the device is
installed in a column
and there is no fixed
connection to the
building.
Note:
Mounting must only be carried out in
an area protected from moisture.
www.behnke-online.de
1 2 3 6
EIA/TIA 568A
Mic Ls
LAN
only possible for 20-0005-BS
Switch
Basic electronics
- +
Port 1
+ RX TX -
IP-camera
GB
Alarm input
5-24 VDC
