Commissioning and Configuration
Operating mode relay 2
12 0 #
1 #
2 #
3 #
4 #
5 #
6 #
7 #
8 #
9 #
10 #
11 #
12 #
13 #
In operating modes 1 to 6, the relay is operated as a door opener relay. You can choose between
a normally open (NO) and normally closed (NC) contact. With the normally open contact, the switch-
ing contact is normally open and will only be closed when the door is to be opened.
With the normally closed contact it is exactly the opposite: the switching contact is normally closed
and will only be opened when the door is to be opened.
Configuration step 13 sets how long the switching contact will be switched. Configuration steps 14
and 15 can be used to define two codes that apply to the indoor intercom station (phone receiving
the call) or the code lock (available via keypad or display), depending on the selected operating
mode.
In all other operating modes, the switching contact behaves like a normally open contact.
So it is usually open.
In operating mode 10, configuration step 13 can be used to define how long the
additional bell is activated at the beginning of the direct call.
In the 'Fault indication' operating mode, a fault is considered to occur when the device no longer
has a valid network connection or when a registration with the SIP server has failed.
82
deactivated
Door opener relay with NC contact, 2 codes for indoor intercom station
Door opener relay with NC contact, 2 codes for code lock
Door opener relay with NC contact, 1 code for indoor intercom station, 1 code
for code lock
Door opener relay with NO contact, 2 codes for indoor intercom station
Door opener relay with NO contact, 2 codes for code lock
Door opener relay with NO contact, 1 code for indoor intercom station, 1 code
for code lock
Connection indicator for outgoing connections
Connection indicator for incoming connections
Connection display for outgoing and incoming connections
Additional bell at the beginning of a direct call
Additional bell during the establishment of a direct call
Additional bell during ringing
Fault indication
Default: 9
