Instructions for Behnke Hybrid series 20-0005-BS, SIP intercoms series 20-0005B-IP
detector or similar functions via the Behnke
bus system of the intercom station.
System requirements
Please observe the following requirements
when installing the Behnke SIP / hybrid inter-
com station:
When connected as SIP intercom station
▸
Network infrastructure with PoE up to the
Behnke station
▸ Network-compatible PC in this network
▸
SIP account, SIP server
▸
When operating without SIP account, SIP
server: End devices that support IP address
dialling and allow operation without SIP
account, SIP server, SIP end devices that
support H.264 communication. Function
should be checked in advance by the speci-
alist company performing the installation.
When connected as a/b intercom station
▸
free a/b port
▸ Power supply via PoE (note the connection
options on page 75 )
Installation conditions
▸
The perfect installation height for your device
is a position that enables operating the door
intercom at a distance of 30-50 cm so the user
can easily speak into the microphone. The
same applies to the use of a camera in this
intercom station.
▸
Please keep the distance between micro-
phone and speaker as large as possible. This
gives you the best possible speech intelligi-
bility in full duplex mode.
www.behnke-online.de
▸
For reverse-side mounting modules
(= mounting behind an existing front wall),
ensure sufficiently large sound inlet slots at
the microphone and sound outlet slots in
front of the loudspeaker (at least 75% of the
loudspeaker membrane area for sound outlet
or 75% of the sound inlet opening on the
microphone housing).
Please note our dimensional drawings on
www.behnke-online.de/downloads
For acoustic reasons, always mount the reverse-
side mounting modules directly (without spa-
cing) and firmly to the back of your front wall.
The gaskets included in the scope of delivery
of our reverse-side mounting modules must be
installed between the reverse-side mounting
module and the rear of the front wall to ensure
unobstructed sound entry and exit.
Outdoor mounting
▸
When using the operating elements on wea-
ther sides, door intercom stations should be
mounted in-wall with a rain protection cover
(please always ensure correct installation of
the supplied gasket).
▸
When mounting the door intercom stations
in surface-mounted housings, cable entry is
possible at the bottom or rear of the surface-
mounted housing. Use the fittings supplied
with the housings.
▸
The unused cable entry must be closed with
the supplied cover angle. The cable entry is
made via the PG fitting.
▸
When mounting all the stations mentioned in
these instructions in-wall, seal the top edge
of the door intercom station well to protect it
against rainwater, especially if the surface is
