Instructions for Behnke Hybrid series 20-0005-BS, SIP intercoms series 20-0005B-IP
VLANs for device and webcam
Connection to a tagged VLAN and providing a second network connection with a tagged VLAN only
for access to the webcam
The VLAN tag for the VLAN of the device can be set via configuration step 79.
The network connection for the webcam can only be configured via the web interface.
WiFi
Connection to a wireless network
In this case, the power supply to the device must be provided either by using a Behnke PoE injector
or ensured by additional connection to a PoE port.
In order to achieve sufficient quality of the radio connection, usually the connection of an external
antenna module is required.
IP address assignment
75 0 # static
1 # dynamic
2 # link-local
Here you can set how the device obtains an IP address.
Static = manual address assignment
The network administrator manages the IP addresses of the network. You have received an
IP- address from the network administrator, which is entered via configuration step 76.
In this case, the associated subnet mask and gateway must also be specified via configuration
steps 77 and 78.
Dynamic = automatic address assignment
There is a DHCP server in the network that manages and distributes the IP addresses. The device
automatically tries to obtain an IP address from this DHCP server.
Link-local = self-assignment of an address
This address assignment is intended for networks without a DHCP server. The device assigns itself a
free IP address in the network 169.254.0.0/16.
The allocated IP address can be queried by pressing the configuration key twice. This type of
address assignment is used when several devices are operated in an independent network as an
IP intercom station.
If there is a DHCP server in the network that assigns an IP address, then this IP address will be used.
In this case, 'dynamic' should be set as address assignment!
www.behnke-online.de
Commissioning and Configuration
GB
Default: 1
