Instructions for Behnke Hybrid series 20-0005-BS, SIP intercoms series 20-0005B-IP
GB
Commissioning and Configuration
Microphone sensitivity
07 0 #
1 #
2 #
:
9 #
*0 #
:
*100 #
The sensitivity of the microphone can be set in levels from 0 (=insensitive) to 9 (=sensitive).
Alternatively, it is possible to set the desired microphone sensitivity in percent (*0 to *100).
Operating mode relay 1
08 0 # deactivated
1 # Door opener relay with NC contact, 2 codes for indoor intercom station
2 # Door opener relay with NC contact, 2 codes for code lock
3 # Door opener relay with NC contact, 1 code for indoor intercom station, 1 code
for code lock
4 # Door opener relay with NO contact, 2 codes for indoor intercom station
5 # Door opener relay with NO contact, 2 codes for code lock
6 # Door opener relay with NO contact, 1 code for indoor intercom station, 1 code
for code lock
7 # Connection indicator for outgoing connections
8 # Connection indicator for incoming connections
9 # Connection display for outgoing and incoming connections
10 # Additional bell at the beginning of a direct call
11 # Additional bell during the establishment of a direct call
12 # Additional bell during ringing
13 # Fault indication
In operating modes 1 to 6, the relay is operated as a door opener relay. You can choose between
a normally open (NO) and normally closed (NC) contact. With the normally open contact, the switch-
ing contact is normally open and will only be closed when the door is to be opened.
With the normally closed contact it is exactly the opposite: the switching contact is normally closed
and will only be opened when the door is to be opened. Configuration step 09 sets how long
the switching contact will be switched.
80
Level 0 (0%)
Level 1 (11%)
Level 2 (22 %)
:
Level 9 (99 %)
0%
:
100 %
Default: *60
Default: 6
