Directed DIRECTECHS DB3 Installation Manual page 9

Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Parking Lights -
Trunk/Hatch Release
9 403.TL1 5.07.106 2013 Toyota Highlander (Smart Key)
©2024 Directed. All rights reserved.
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
(-) Aux1 Input
No Connection
No Connection
No Connection
(+) W2W Only - Starter Input
(+) W2W Only - Ignition Input
(-) W2W Only - Ground When Running (Status) Input
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
dash fuse box, white 1 pin plug (1A), pin 1
headlight switch, black 20 pin plug, pin 18
driver kick, gray 12 pin plug, pin 1; black 18 pin plug, pin 13
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
Remote Starter
Remote Starter
Remote Starter
(+/-)
+
-
-
(+/-) Wire Color
Description
Description
Wire Color
black (140A or 150A)
lt. blue
yellow (liftgate); beige (glass) (rear handle switch)
