PDR8000® Portable Digital Repeater and Booster Pack Deployment Guide
Main Menu Sub-Menu
>CHANNELS >List of Channels
<List of Deployment Profiles
>DEPLOYMENTS
>SETTINGS >CONTRAST
>BRIGHTNESS
>TIME/DATE
>KEYPAD TONE
>LOCK KEYPAD
>DIAGNOSTICS >RSSI
>LINK
>LINK >NONE
>V.24 ON/OFF
>DFSI ON/OFF
December 2023
xxx
►►►
(below, if link = DFSI)
>SIP: x.x.x.x
>SUB: x.x.x.x
>SCP: X
>SVP: X
(below, if link established)
>HIP: x.x.x.x
>HCP: X
>HVP: X
>HB: X
Document 8K088X03 R5.04
Action/Info
View/Select Active Channel
View/Select Active Deployment Profiles
View/Set Display's Contrast Level
View/Set Display's Brightness Level
View/Set the following
◄Time Zone UTC+/- H:MM ►
◄DST ENABLED/DISABLED ►
◄YEAR YYYY ►
◄MONTH MM ►
◄DAY DD ►
◄HOUR HH ►
◄MINUTE mm ►
◄SECOND SS ►
Toggle keypad tone ENABLED/DISABLED
Lock keypad access
View Received Signal Strength (RSSI) value
Note: RSSI Threshold levels correspond to the level
at the PDR8000 antenna port. PDR8000 attempts to
compensate for duplexer losses but is limited by the
maximum receiver sensitivity.
Shows link quality of the V.24 or Ethernet
Network: ► (poor) or ►► (marginal) or ►►►
(good)
Indicates no wireline link is configured in the
active Deployment Profile
Indicates V.24 link is configured in the active
Deployment Profile, and whether the link is
established
Indicates DFSI link is configured in the active
Deployment Profile, and whether the link is
established
Station IP Address of the DFSI station
Subnet of the DFSI station
DFSI Station's Control Port number
DFSI Station's Voice Conveyance Port number
DFSI Host's IP Address
DFSI Host's Control Port number
DFSI Host's Voice Conveyance Port number
Heartbeat in Seconds between DFSI host and
station
