PDR8000® Portable Digital Repeater and Booster Pack Deployment Guide

Figure 20 - PDR8000 Dedicated Status LEDs Definition

Side LED States
The following table contains the status definitions for the side LED.
State
ON
FLASH SLOW
FLASH FAST
OFF
If the PDR8000 does not successfully power up, the fan will not start running and there will be
no lights displayed on the LED light panel. Disconnect the power source and replace the
appropriate fuse.
DC Power- the DC fuses are located inside the PDR8000. Contact Futurecom for service: 1-
800-701-9180 or support@futurecom.com
AC Power- the AC Fuse is located inside the Duplexer compartment. Unscrew the four screws
and remove the top panel as shown in Figure 6 and Figure 7. The fuse is in the bottom right
corner. Unscrew the fuse cover counterclockwise to remove it and replace the fuse
(Manufacturer: Bel, Part Number: 5ST5-R, 5Amps).
December 2023
PDR8000 is operating normally.
PDR8000 is operating, but under an abnormal or
warning condition. This includes operating in
Fallback In-Cabinet Repeat when the wireline link
has ceased communication. (See front panel LEDs,
front panel display, or technicians log to gain
further insight.)
PDR8000 is not functioning. A major error has
occurred. (See front panel LEDs, front panel
display, or technicians log to gain further insight.)
PDR8000 is powered down or LED has been
disabled via configuration.

Figure 21 - PDR8000 Side LED Definition

Document 8K088X03 R5.04
Status Description
Page 17 of 35
