Figure 11 - Pdr8000 Side Panel; Figure 12 - Pdr8000 External Connectors' And Led Specifications - Futurecom PDR8000 Deployment Manual

PDR8000® Portable Digital Repeater and Booster Pack Deployment Guide
ID Label
1 V.24
1
2 LAN
0F
3 13V/7A DC
4 100-240V/4A AC
5 AUX
6 ANTENNA
7 RF OUT
8 RF IN
9
10
Green LED Indicator

Figure 12 - PDR8000 External Connectors' and LED Specifications

1
LAN port is not enabled on PDR8000
2
Connector was EGG.1K.306.CLL on releases prior to PDR8000 Release 4
December 2023

Figure 11 - PDR8000 Side Panel

Type Manufacturer
RJ-45 CONEC
RJ-45 CONEC
DC Power Input LEMO
AC Power Input NEUTRIK
Circular Receptacle LEMO
N Female N/A
N Female N/A
N Female N/A
Ground Lug NA
N/A
Document 8K088X03 R5.04
Model Ref* Open/Close Mechanism
17-111574 Screw/Unscrew Dust Cap
17-111574 Screw/Unscrew Dust Cap
EGL.2K.302. Push Pull Dust Cap
CLA
NAC3MPX Push Pull Sealing Cover
EGG.1K.308 Push Pull Dust Cap
2
.CLL
1F
N/A Screw/Unscrew Dust Cap
N/A Screw/Unscrew Dust Cap
N/A Screw/Unscrew Dust Cap
N/A N/A
N/A N/A
