7.3
Connecting to the Wi-Fi Hotspot
Prior to attempting to connect to the Wi-Fi hotspot, make sure the Wi-Fi is enabled and the Wi-Fi status is "Connected".
If security is set to WPA-PSK, the password is needed to connect. Using a Wi-Fi capable device, browse the available Wi-Fi
connections and select the SSID that matches the network name set on the Wi-Fi hotspot page. If required, enter the
password that was defined when configuring the current active Wi-Fi Hotspot.
Figure 35 - Wi-Fi SSID
Once connected to the Wi-Fi hotspot, enter 172.27.72.1 in the address bar of an internet browser to view the device
discovery page. The device discovery page lists each iLINQ controller connected to the room terminal. The device name
is listed in the third column and can be used to distinguish iLINQ controllers from each other. The unit number of the
iLINQ controller is the numerical portion of the device name. To access an iLINQ controller's web interface, click the
corresponding row or enter it's IP address into the address bar of the web browser.
Device Name
Daikin-iLINQ-UnitNumber.local
iLINQ Room Terminal
Figure 36 - Device Discovery
33
