Installation Instructions

This section contains installation instructions for the iLINQ Room Terminal accessory.
3.1

Electrical Wiring

As illustrated in Figure 1, electrical wiring connections between the room terminal and the RTU are required for this
accessory. In most installations this will require wiring to be routed through roofing, floors, and walls. All installation
materials needed to route the wiring from the room terminal to the RTU are to be supplied by the installer. Use care to
avoid routing field wiring near hazardous voltage circuits both inside the building and the RTU.
Install electrical wiring in accordance with all local electrical and NEC codes. Review the main unit IO manual for the
location of the low voltage wire entrance. Wiring should be in place prior to component installation. Review Wiring
Specifications section for additional detail and point to point connections. Use wire ties provided with kit to secure any
excess field wiring.
3.2

Room Terminal Enclosures:

The room terminal serves as the RTU's source of space temperature and humidity. With that in mind, the installation of
the room terminal enclosure must meet the following requirements:
• In the space served by the RTU
• In/On the wall approximately 4 feet above the finished floor
• Avoid heat sources such as radiators or direct sunlight
• Avoid installing near sources of air drafts such as HVAC supply vents
• Avoid installing in aggressive or polluting atmospheres (salt spray, sulfur/ammonia fumes, smoke)
• The length of power and communication wiring must not exceed the maximum distance outlined in the electrical
wiring specifications
Surface Mount: Use two fasteners appropriate for the material of the wall to attach the mounting bracket to the wall.
Remove the knockout if an Ethernet connection is required.
Flush Mount: Use the flush mount box as a template to trace the dimensions of the cutout needed. Cut wall opening,
route wires through a knock out in the enclosure, and push enclosure into the wall. Tighten the screws until the
enclosure is fastened securely to the wall.
3.3

Room Terminal

The room terminal is secured to the enclosure using the two screws provided with the room terminal. Once the wire
terminations have been made in the last step of the installation, use the fastening screws to attach the room terminal
to the mounting enclosure. The room terminal mounting orientation should be such that the LED side bar is on the right
side and the temperature/humidity sensor is in the bottom left corner.
3.4

Frame

Install the frame by pressing it onto the face of the room terminal. The frame will snap into position when installed
correctly.
