The configuration settings are organized in a scrollable table. Press and drag in the table area to scroll through the
options.
5.9.2

Page Appearance Settings

The page appearance settings are configured via toggle switches and are described in the following table.
Setting
Display CO2
Display Humidity
Display iLINQ
Display Date/Time
Display Unit #
Page Navigation Lockout Disabled
5.9.3

LCD Display Settings

The LCD display settings are configured via keypad and are described in the following table.
Setting Range
Display Timeout 0, 60-10, 020 seconds
(rounds up to next highest
multiple of 60)
Display Brightness 0-100%
5.9.4

Password Protection Settings

The password protection settings are configured via a keypad/toggle switch and are described in the following table.
Setting
User Adjust Password 0000-9999 0000
Occupancy Override
Password Protect
5.9.5

LED Behavior Settings

The LED sidebar settings are configured via toggle switches and are described in the following table.
Setting Default State
HVAC Mode LED Enabled
Enabled
Alarm Indicator LED (optional, only if HVAC
Mode LED is enabled)
Default State Description
Disabled Toggles the visibility of the CO2 value on the home and detail pages
Enabled Toggles the visibility of the space humidity value on the home page
Disabled Toggles the visibility of the link to the iLINQ summary pages
Enabled Toggles the visibility of the date/time on the home and detail pages
Enabled Toggles the visibility of the unit number on the home and detail pages
Toggles the visibility of the page navigation tabs on the home page. Restricts
access to the detail and live trend pages.
Range Default State
N/A Disabled
Description
Enables the LED sidebar to indicate current HVAC mode of operation via
color
Enables the LED sidebar to indicate current HVAC alarm state via flashing
Default Value Description
900 seconds LCD backlight delay off timer (in seconds)
Timer resets when the screen is touched
If off, the LCD backlight turns on when screen is
touched
If set to 0, the backlight remains on with no timeout
(not recommended)
100% Controls the brightness of the LCD backlight
Description
Password that is required to access the space temperature
setpoint adjust page
If this password = 0000, access to the space temperature setpoint
adjust page is not password protected
When enabled, the user is required to enter the user adjust pass-
word to override the controller's occupancy
If the user adjust password = 0000, the occupancy override pass-
word protect row is hidden
