5.11
Wi-Fi Hotspot Page
The Wi-Fi hotspot page is described in the iLINQ network guide section of this document.
5.12
Controller Display Emulator Page
The controller display page is an emulator of the iLINQ controller's onboard LCD. This page can be used to make
advanced parameter adjustments, change the unit schedule, etc. While the controller display page is active, the space
temperature and humidity are not transmitted to the controller. For this reason, the controller display page should not
be used for an extended amount of time during occupied hours. Refer to the iLINQ DDC User Manual for additional
information about the onboard LCD.
5.12.1 Overview
Item #
Item
1
Alarm
2
Menu
3
Escape
4
Up
5
Enter
6
Down
7
Select Multiple Tap to select multiple LCD keys
8
Hold
①
②
③
Figure 28 - Controller Display Page
Description
Tap to view active alarms
Indicates unit alarm status by blinking red
Tap to navigate to the main menu screen
Tap to return to the previous screen
Tap to scroll through menu screens, or modify selected values
Tap to select a highlighted option or apply a modified value
Tap to scroll through menu screens, or modify selected values
Once multiple LCD keys are selected, tap to simulate a press and hold
⑦
⑧
④
⑤
⑥
26
