The BLIP2 evaluation system contains ESD (electrostatic discharge) sensitive
devices. Electrostatic charges readily accumulate on the human body and
equipment and can discharge without detection. Permanent damage may
occur on devices subjected to high-energy discharges. Proper ESD precau-
tions are recommended to avoid performance degradation or loss of function-
ality. Store unused BLIP2 boards in the protective shipping package.

BLIP2 Board Installation

It is assumed that the CrossCore Embedded Studio software is installed
and running on your PC.
Follow these instructions to ensure correct operation of the product soft-
ware and hardware.
Step 1: Connect an emulator to the BLIP2 board.
1. Plug one side of the included USB cable into the USB connector of
the emulator. Plug the other side into a USB port of the PC.
2. The status LED (labeled
with the PC is working and the appropriate Windows driver is
installed. Please refer to the appropriate emulator manual if the sta-
tus LED does not turn on.
3. Attach the emulator header (
the connector on the BLIP2 board.
P3
ADZS-BF707-BLIP2 Board Evaluation System Manual
Using ADZS-BF707-BLIP2 Board
) lights up yellow if the connection
STATUS
) on the bottom of the ICE-1000 to
J2
1-3
