To create a debug configuration, do one of the following:
• Click the down arrow next to the bug icon
Debug Configurations.
• Choose Run > Debug Configurations.
The Debug Configuration dialog box appears.
3. Select CrossCore Embedded Studio Application and click
(New launch configuration).
The Select Processor page of the Session Wizard appears.
4. Ensure Blackfin is selected in Processor family. In Processor type,
select ADSP-BF707. Click Next.
The Select Connection Type page of the Session Wizard appears.
5. Select Emulator and click Next.
The Select Platform page of the Session Wizard appears.
6. Choose the type of emulator that is connected to the BLIP2 board.

An ICE-1000 emulator is included in the package.
7. Click Finish to close the wizard.
The new debug configuration is created and added to the Debug
Configurations list.
8. In the Name edit box, users can select an appropriate name to
describe the configuration, otherwise a default name is provided.
9. Select the Custom Board Support tab and check the Enable cus-
tomizations box. Click on Browse and select the
ADZS-BF707-BLIP2-proc.xml file found in the
ADZS_BF707_BLIP2_Board-Rel1.0.0\Blackfin\Examples folder.
ADZS-BF707-BLIP2 Board Evaluation System Manual
Using ADZS-BF707-BLIP2 Board
, select
1-5
