A ADZS-BF707-BLIP2 BOARD
BILL OF MATERIALS
The bill of materials corresponds to
Schematic.
Ref. Qty. Description
1 1 SN74LVC1G08 SOT23-5 U11
2 1 24MHZ OSC013
3 1 24MHZ OSC013
4 1 W25Q32 SO8W
5 1 FT232RQ
QFN50P500X500-33NA
6 1 ADP2230
DFN50P300X300-11N
7 1 ADP2370ACPZ-R7
DFN50P300X300-9N
8 1 LTC6993CS6-3
SOT95P280-6N
9 1 OVM7692-RACA
BGA25C50X54P5X5_282
X318
10 1 SN74LVC2G14DCKRQ1
SOT65P210-6N
11 1 ASX340AT2C00XPED0
BGA63C65P8X8_7500X7
500_SCKT
ADZS-BF707-BLIP2 Board Evaluation System Manual
ADZS-BF707-BLIP2 Board
Reference Manufacturer
Designator
TI
Y1 DIGI-KEY
Y2 DIGI-KEY
U8 WINBOND
U15 DIGI-KEY
U13 ANALOG
DEVICES
U1 ANALOG
DEVICES
U12 LINEAR TECH
U4 OMNIVISION
TECH
U14 DIGI-KEY
U10 APTINA
Part Number
SN74LVC1G08DBVE
535-9138-2-ND
535-9138-2-ND
W25Q32FVSSIG
768-1008-1-ND
ADP2230
ADP2370ACPZ-R7
LTC6993CS6-3#TRMPBF
OVM7692-RACA
296-13011-1-ND
ASX340AT2C00XPED0
A-1
