Ruijie RG-S6910-3C Series Switches
Hardware Installation and Reference Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-S6910-3C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruijie RG-S6910-3C Series

Summary of Contents for Ruijie RG-S6910-3C Series

  • Page 1 Ruijie RG-S6910-3C Series Switches Hardware Installation and Reference Guide...
  • Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
  • Page 3 Appendix B "Mini-GBIC, 10G, 40G and 100G Modules"  Appendix C “Lightening Protection”  Appendix D “Cabling Recommendations in Installation”  Appendix E “Site Selection” Obtaining Technical Assistance  Ruijie Networks Website: https://www.ruijienetworks.com/  Technical Support Website: https://ruijienetworks.com/support  Case Portal: https://caseportal.ruijienetworks.com ...
  • Page 4 Describes network protocols and related mechanisms that supported by the Configuration Guide product, with configuration examples. Describes the related configuration commands, including command modes, Command Reference parameter descriptions, usage guides, and related examples. Symbol Conventions Means reader take note. Notes contain helpful suggestions or references. Means reader be careful.

  • Page 5: Product Overview

    RG-S6910-3C series switches are data center oriented high density 100G core switches, providing 100G access, low latency, and complete data center features . RG-S6910-3C series switches provide 96 100G ports and can be used with other aggregation switches to compose a high-performance and high-reliability data center network.
  • Page 6 Static power: 760 W, typical power: 1092 W, power with full load: 2046 W Consumption Refer to Appendix B Optical Module The supported modules update at any time, contact Ruijie Networks for details . SFP28 Port Unsupported QSFP28 Port Supported. The number of ports depends on the expansion module.
  • Page 7 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Overview Front Panel Figure 1-2 Front Panel of the RG-S6910-3C Notes: Engine Slot System Status Indicator USB Port FIND Status Indicator MGMT Port Expansion Module Slot MGMT Indicator Mounting Bracket Console Port Rear Panel Figure 1-3 Rear Panel of the S6910-3C...
  • Page 8 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Overview Notes: Fan Module Slot Grounding Point Fan Indicator ESD Wrist Strap Power Module Slot Asset Tag Asset Tag The asset management label is in the lower left corner of the rear panel. The label is movable and can be removed from the device.
  • Page 9 To protect the data and avoid device damage, use qualified USB flash disks of good brands. At the same time, the local USB port is compatible with most of the USB controllers except some USB flash disks. RG-S6910-3C series switches support debugging, configuration, maintenance, management and switch software uploading of Console ports.
  • Page 10 The port is transmitting or receiving data at 100Gbps. When the device works properly, its FIND indicator is solid green. If there are too many RG-S6910-3C series switches to locate a specific device, you can run the led-blink enable/disable command to configure the FIND indicator to blink at 1Hz in red, so as to locate the device.
  • Page 11 The power module and fan module with different ventilation direction cannot be used together. 1.2 Modules The RG-S6910-3C series switches adopt the module-based design. Compliant with industry standards, the design divides modules and integrates module interfaces to ensure the switch system's functioning and independence of various function modules.
  • Page 12 420 mm x 203.5 mm x 42 mm (16.5 in. x 8.01 in. x 1.65 in.) (W x D x H) QDFP28 ports of M6900-32CQ support 100G/40G mode and 4x25G/4x10G mode. Please configure the port to work in the corresponding mode based on RG-S6910-3C Series Switch RGOS Configuration Guide. - 10 -...
  • Page 13 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Overview When the QSFP28 ports of M6900-32CQ is divided into 4x25G mode or 4x10G mode, the port configuration takes effect based on the port group instead of an individual port, and four consecutive 100G ports form a port group. For example, if the port hun 1/1 is divided, ports hun 1/1 -4 are divided at the same time.
  • Page 14 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Overview Notes: Handle Screw Status Indicator Indicator Panel Indicator Status Meaning Identification The fan is not powered on. Blinking green The fan is being initialized. Status Indicator Status Solid green The fan works properly.
  • Page 15 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Overview Rotation 11000 RPM Speed Consumption 44.4 W Weight 0.25 kg (0.55 lbs) Dimension(W x 166 mm x 83 mm x 83 mm (6.54 in. x 3.27 in. x 3.27 in.) D x H) 1.2.3 RG-PA1200I-F RG-PA1200I-F is a smart power supply for RG-S6910-3C, obtaining power status, output power, current and working...
  • Page 16 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Overview Indicator Panel Indicator Status Meaning Identification There is no power input or the power supply fails. Solid green The power input is normal. The power is PS off, 12VBS. Blinking green at 1 Hz The power is in cold backup status and does not output power.

  • Page 17: Preparation Before Installation

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Preparation before Installation 2 Preparation before Installation 2.1 Safety Precautions To avoid body injury and device damage, please carefully read the safety precautions before you install the RG- S6910-3C. The following safety precautions do not cover all possible dangers. 2.1.1 Installation Safety ...

  • Page 18: Laser Safety

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Preparation before Installation  Find out the location of the emergency power supply switch in the room before installation. First cut off the power supply in the case of an accident. ...
  • Page 19 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Preparation before Installation 2.2.1 Rack Mounting Requirements Make sure the cabinet complies with the following conditions if the RG-S6910-3C is installed in the cabinet:  Install the switch in an open cabinet as much as possible. If you install the switch inside a closed cabinet, be sure that the cabinet has a good ventilation and heat dissipation system.

  • Page 20: System Grounding Requirements

    All the above constitute the comprehensive grou nding requirements. The grounding resistance should be less than 1Ω. There is one grounding connector at the left bottom of the chassis of RG-S6910-3C series switches. The grounding connector is pasted with conspicuous warning labels.

  • Page 21: Emi Consideration

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Preparation before Installation 2.2.6 EMI Consideration Various interference sources, from either outside or inside the device or application system, affect the system in the conductive ways such as capacitive coupling, inductive coupling, and electromagnetic radiation. There are two types of electromagnetic interferences: radiated interference and conducted interference, depending on the type of the propagation path.

  • Page 22: Unpacking And Checking

    Air-laid paper, fiber end microscope Meter Multimeter, errormeter, optic-power meter RG-S6910-3C series is not shipped with a tool kit. You need to prepare a tool kit by yourself. 2.5 Unpacking and Checking Goods Checklist Chassis, Yellow/green grounding cables, Quick installation guide, Packing list, Pouched...

  • Page 23: Product Installation

    Product Installation 3 Product Installation RG-S6910-3C series Ethernet switch must be used and fixed in the room. Make sure you have carefully read part 2, and be sure that the requirements set forth in part 2 have been met. 3.1 Installation Procedure...

  • Page 24: Cabinet Installation

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation  The related network cables have already been deployed at the installation location. 3.3 Cabinet Installation Precautions When you install the cabinet, pay attention to the following requirements:  All expansion bolts for fastening the cabinet base to the ground should be installed and tightened in sequence from bottom up (large plain washer, spring washer, and nut), and the installation holes on the base and the expansion bolts should be well aligned.

  • Page 25: Mounting The Switch To A Rack

    3.4.1 Mounting the Switch to a Rack The RG-S6910-3C series switches are qualified for EIA standard and can be installed in a 19-inch wiring cabinet. During the process of installation, keep the front panel of the switch forward. It is recommended use tray to install the RG- S6910-3C series switches and fix the tray on the bracket, or use the rear bracket pro vided with the switches.
  • Page 26 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation Place the switch on the rack and slowly push the switch until the lugs on both sides of the front panel align the cage nuts on the cabinet column. Figure 3-3 Installing Switch Use a cross screwdriver to tighten the screw on the lug to the nut.

  • Page 27: Mounting The Switch To A Workbench

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation Distinguish the left and the right rear brackets according to the marked directions. The rear brackets provided are only applicable for cabinets with depth of 800mm to 1200mm. 3.4.2 Mounting the Switch to a Workbench In some cases, users do not have the 19-inch standard cabinet.
  • Page 28 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation Tighten the captive screws with a screwdriver to fix the fan module in the switch chassis . Figure 3-5 Installing a Fan Module Insert the fan module smoothly. Pay attention to the direction of the fan panel to avoid wrong insertion. If the position is not proper, pull out the inserted module and re-insert it.
  • Page 29 Installing an M6900-32CQ Series Expansion Module Take off the filler panel in the expansion module slot on the front panel of a RG-S6910-3C series switch. Pull out the levers on both sides of M6900-32CQ. Hold the bottom of expansion m odule with one hand, align M6000E to the guide rail of the expansion module slot with the other hand, and push it to the switch along the rail horizontally and slowly.
  • Page 30 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation Insert the expansion module smoothly. Pay attention to the direction of the expansion panel to avoid wrong insertion. Do not hold the edge of the PCB or collide the components on the PCB. If it is difficult or even impossible to insert the module, pull out the module, make sure the expansion module and guide rail are well aligned, and then insert the module again.
  • Page 31 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation Pull out the expansion module uprightly and slowly. Do not hold the edge of the PCB or collide the components on the PCB. Install a filler panel on the location where an expansion module is removed to ensure normal ventilation and dissipation and avoid dust in the chassis.
  • Page 32 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation Install a filler panel in the power module slot and put the removed power module into its package. Figure 3-2 Removing a Power Module Remove the power module slowly. Install a filler panel in the location where the power module is removed to ensure the normal ventilation and dissipation and avoid the dust in the chassis.

  • Page 33: Connecting The External Interface Cables

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation The cross-sectional area of protective grounding conductor should be at least 2.5 mm2 (12 AWG). 3.9 Connecting the Cables of the Management Serial Ports Simple Connection Steps Connect the RJ45 connector to the Console interface of the management engine module with shipped console cable, and connect the DB9 connector to the NM or control terminal.
  • Page 34 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Product Installation 3.12 Installation Verification Verifying the Cabinet  Verify if the external power supply matches the distribution panel of the cabinet.  After equipment is installed, verify if the front/back cabinet doors can be closed. ...

  • Page 35: System Debugging

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide System Debugging 4 System Debugging 4.1 Establishing the Configuration Environment Establishing the Configuration Environment Connect the PC to the console port of the switch through the console cable, as sho wn in Figure 4-1. Figure 4-1 Schematic diagram of the configuration environment Connecting the Console Cable Connect one end of the DB-9 jack of the console cable to the serial port of the PC.
  • Page 36 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide System Debugging Figure 4-2 Enter the name of the new connection and click OK. A window appears as shown in Figure 4-3. In the column of Connect Using field, select the serial port you want to use. Figure 4-3 After the serial port is selected, please click OK.

  • Page 37: Power-On Startup

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide System Debugging After the serial port parameters are set, click OK to enter hyper terminal window. 4.2 Power-on Startup Checking before Power-on  Check if the switch is fully grounded.  Check if the fan module and the power module are correctly installed.

  • Page 38: Monitoring And Maintenance

    Working status of fan and power supply  Temperature status For the monitoring commands, refer to RG-S6910-3C Series Switch RGOS Configuration Guide. 5.2 Hardware Maintenance Expansion Module Maintenance To replace a board, do replacement according to the instructions provided in Sections of Installing Modules and Removing Modules.
  • Page 39 Replacing Lithium Battery The built-in lithium batteries can support the real time clock of the RG-S6910-3C series switches without external power supply. Please contact the technical support representatives of Ruijie Networks for replacing lithium batteries. Technical staff of Ruijie Networks will replace the battery of the same model.

  • Page 40: General Troubleshooting Procedure

    Check the indicators on the device and the modules Check the connection of the serial ports and its parameters Check the connection of the fibers or cables of various ports Contact Technical Support of Ruijie Networks for hardware problems - 38 -...

  • Page 41: Troubleshooting Common Faults

    RG-S6910-3C Software Configuration Guide. If not, modify the serial port configuration parameters. If there is still no serial port p rinted information, please contact Ruijie Customer Service Department for technical support.
  • Page 42 Check whether the module is inserted correctly. If the newly-inserted module still cannot be powered on even though the checking is ok, please contact Ruijie Customer Service Department for technical support. Fault 7: The link cannot be set up between fiber interfaces [Fault Description] The system runs normally.

  • Page 43: Appendix A Connectors And Connection Media

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Appendix A Connectors and Connection Media 10GBASE-T/1000BASE-T/100BAS E-TX Port 10GBASE-T/1000BASE-T/100BASE-TX is a port that supports self-adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. 10GBASE-T complies with IEEE 802.3an standard, and the supported cables and cabling distances are listed in the following table.
  • Page 44 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Figure A-1 Four twisted pairs of the 1000BASE-T In addition to the above cables, the 100BASE-TX can use up to 100m of 100-ohm CAT5. Figure A-2 shows the definition of pin signal concerning the 100BASE-TX: Figure A-2 Definition of pin signal concerning the 100BASE-TX Socket...

  • Page 45: Appendix B Mini-Gbic, 10G, 40G And 100G Modules

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix B Mini-GBIC, 10G, 40G and 100G Modules Appendix B Mini-GBIC, 10G, 40G and 100G Modules We provide mini-GBIC module, 10G SFP+ modules, 40G QSFP+ modules, 100G QSFP28 modules. According to the interface type of the switch module.
  • Page 46 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix B Mini-GBIC, 10G, 40G and 100G Modules Intensity of Intensity of Modular Optical Core Wavelength Bandwidt Transmitted Received Model Fiber Size Cabling (nm) Light (dbm) Light (dbm) (μm) Type distance (MHz·km) 62.5 XG-SFP-SR-...
  • Page 47 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix B Mini-GBIC, 10G, 40G and 100G Modules 25GE, 1m, SFP28 Passive SFP28 25.78125 25GE, 3m, SFP28 Passive SFP28 25.78125 25GE, 5m, SFP28 Passive SFP28 25.78125 Models and Technical Specifications of the 40G QSFP+ Module 40G QSFP+ optical modules Intensity Wavel...
  • Page 48 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix B Mini-GBIC, 10G, 40G and 100G Modules 100G- QSFP- -4.3 to 4.5 -10.6 to 4.5 1310 SMF (LC) 10km LR4- (Perlane) (Perlane) SM1310 100G QSFP28 copper modules Copper Conductor Support Module Connector Data...

  • Page 49: Appendix C Lightning Protection

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix C Lightning Protection Appendix C Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row should be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch.
  • Page 50 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix C Lightning Protection Installing the Ethernet Port Arrester During the switch usage, the Ethernet port arrester should be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the swi tch . Tools: Cross or straight screwdriver, Multimeter, Diagonal pliers Installation Steps: Tear one side of the protection paper for the double-sided adhesive tape and paste the tape to the framework of the...
  • Page 51 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix C Lightning Protection You should pay attention to the following conditions during the actual installation to avoid influencing the performance of the Ethernet port arrester:  Reversed direction of the arrester installation. You shall connect the external network cable to the “IN” end and connect the switch Ethernet port to the “OUT”...

  • Page 52: Appendix D Cabling Recommendations In Installation

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Appendix D Cabling Recommendations in Installation When the switches are installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cable management bracket, and top cabling or bottom cabling is adopted according to the actual situa tion in the equipment room.
  • Page 53 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation  Cables of different types (such as power cords, signal cables, and grounding cables) should be separated in cabling and bundling and no mixed bundling is allowed. When they are close, crossover cabling can be adopted. In the case of parallel cabling, power cords and signal cables should maintain a distance not less than 30 mm.
  • Page 54 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Figure D-3 Bundling up cables (3)  Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot.
  • Page 55 RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix D Cabling Recommendations in Installation Figure D-4 Cable fastening  The hard power cable should be fastened at the terminal connection area to prevent stress on terminal connection and cable. ...

  • Page 56: Appendix E Site Selection

    RG-SS6910 3C Series Switch Hardware Installation and Reference Guide Appendix E Site Selection Appendix E Site Selection  The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant.
