Maxxus 4.2 Installation & Operating Manual page 7

Assembly
Step 2: Mounting the Front Stand
Attach the front stand with transport rollers (B) with two 3/8" hexagon head
screws (2), four 3/8" washers (1) and two 3/8 "cap nuts (8) to the front mount-
ing of the base frame (1).
8
B
A
1
2
ENG
D
Step 3: Mounting the Steering Column
Connect the end of the cable that extends from the bottom of the handlebar
stem (D) to the end of the cable that protrudes from the base frame (A). Now 3
place the handlebar stem (D) on the base rame (A) and x it with our hexa-
gon nuts M8 (3).
WARNING:
When inserting and securing the handlebar stem, make sure that you do not
crush or damage the cables.
A
7
