Cockpit
Functions
The cockpit has 6 function buttons: UP, DOWN, RESET, START/STOP, RECOVERY and MODE.
A. UP : Selection of the function and increase of values.
B. DOWN : Selection of function and decrease of values.
C. RESET: Reset in Stop Mode.
D. START/STOP : Start and stop programs.
E. RECOVERY : Recovery pulse test function.
F. MODE : In Stop Mode to conrm inputs and access the training program.
Display
Switching on: Plug the power adapter into the power socket of the bike and connect it to the mains (230V). The
display shows all segments of the cockpit for about 2 seconds.
A. Level : Displays the resistance levels (LEVEL 1 to LEVEL 16).
B. Resistance proles:
20 Resistance columns in 8 rows are displayed.
C. Time display:
D. Display of speed and revolutions (RPM)
