Hardware Installation and Reference Guide
Confirm the location of the emergency power switch in the room. When an accident occurs,

turn off the power switch immediately.

Cable Connection

1.11
Warning
Use the power cord that is delivered with the device to avoid safety accidents.
After the device is installed in the cabinet, you need to connect the device to external device
ports by the following steps:
Connect the power cord delivered with the device into the system power in turn.
(1)
Ensure that the main power is turned off before you insert the power plug, and connect the
(2)
power cord plug to the power outlet.
Connect the system network with the network cable through a standard RJ45 port.
(3)

Check After Installation

1.12
If the device is installed in a cabinet, check whether the installation angle brackets of the

cabinet and the device are firm. If the device is placed on a workbench, check whether
there is enough heat dissipation space around the device and whether the workbench is
stable.
Check whether the power cord meets the standard specifications of the cloud server.

Check whether the cabinet is properly grounded.

Check whether the connections between the device and other devices such as the

configuration terminal are correct.
Check whether the length of the power cord is sufficient to prevent the power cord from

being tensioned.
4

Verifying Operation Status

Setting Up Configuration Environment

1.13
Connect the PC to the Console port of the device through a configuration cable, as shown in
the following figure:
15
Verifying Operation Status
