- Page 1 Ruijie RG-AM5528-SF All-Optical i-Share+ Master Access Point Hardware Installation and Reference Guide Document Version: V1.3 Date: August 16, 2023 Copyright © 2023 Ruijie Networks...
- Page 2 Some or all of the products, services or features described in this document may not be within the scope of your purchase or use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement or guarantee for the content of this document.
-
Page 3: Preface
Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com Technical Support Email: service_rj@ruijienetworks.com... - Page 4 2. Signs The signs used in this document are described as follows: Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.
-
Page 5: Table Of Contents
Contents Preface ....................................I 1 Product Overview ................................1 1.1 Overview ................................1 1.2 Package Contents ..............................2 1.3 Appearance ................................2 1.3.1 Front Panel ............................2 1.3.2 Rear panel ............................. 4 1.3.3 Power Supply ............................4 1.3.4 Heat Dissipation ..........................4 1.4 Technical Specifications ..........................5 1.4.1 Dimensions and Weight ........................ - Page 6 1.6 Installation Environment Requirements .....................9 1.6.1 Load-bearing Requirements ......................9 1.6.2 Ventilation Requirements ........................9 1.6.3 Space Requirements ...........................9 1.6.4 Temperature and Humidity Requirements ................. 10 1.6.5 Cleanliness Requirements ......................10 1.6.6 Grounding Requirements ......................... 11 1.6.7 Anti-interference Requirements ....................12 1.6.8 Lightning Protection Requirements ..................... 12 1.6.9 Checking the Installation Conditions ...................
- Page 7 1.16 Hardware Maintenance ..........................17 1.16.1 Heat Dissipation System Maintenance ..................17 6 Appendix ..................................18 1.17 Connector and Connection Media Description ..................18 1.18 SFP Module Type and Technical Specifications .................. 20 1.19 10G SFP+ Module Description ........................21 1.20 Lightning Protection of All Optical i-Share Master AP ..............
-
Page 8: Product Overview
Product Overview Overview RG-AM5528-SF is an all optical i-Share master AP launched by Ruijie Networks based on the wireless simplified Ethernet solution for complex application environments, such as wireless dormitory networks, hotel networks, and dense office networks. RG-AM5528-SF provides 4 uplink 10G SFP ports and 24 downlink 1G/2.5G SFP ports, supporting optical APs for 24... -
Page 9: Package Contents
Spring clip Appearance The front panel of RG-AM5528-SF provides 24 1G/2.5G downlink SFP ports, 24 PoE power feeding ports, 4 10G SFP Plus ports, 1 management Ethernet port (MGMT), and 1 Console port. The rear panel provides AC power input port. The product appearance is as follows:... - Page 10 Hardware Installation and Reference Guide Product Overview Front panel description Table 1-2 Number Button and Port Function Description Console port Communication serial port MGMT port Ethernet port for management PoE power feeding port PoE power feeding port PoE status indicator Steady green: power supplied;...
-
Page 11: Rear Panel
Heat Dissipation 1.3.4 RG-AM5528-SF uses a built-in cooling fan. The left and front panels provide air inlets, and the right panel provides air outlets to ensure that the device works normally in the specified environment. There should be a space of 10 cm on the left/right sides and the front panel of the chassis to facilitate air circulation. -
Page 12: Technical Specifications
Hardware Installation and Reference Guide Product Overview Technical Specifications Dimensions and Weight 1.4.1 Dimensions and Weight RG-AM5528-SF Dimensions (W × D × H) 442 mm × 315 mm × 43.6 mm (17.40 in. x 12.40 in. x 1.72 in.) Rack Height Installation Mode Rack Port Specifications 1.4.2... -
Page 13: Power Supply And Consumption
Frequency: 50–60 Hz Rated current: 4 A Note The supported SFP module models may be updated without notice. For details, contact Ruijie Networks Customer Service Department. PoE/PoE+/PoE++ comply with IEEE802.3af, IEEE802.3at, and IEEE802.3bt. The actual PoE load capacity should be calculated based on the total available PoE power of the power supply and the actual power of the PoE devices. -
Page 14: Installation Preparation
Hardware Installation and Reference Guide Installation Preparation Environment and Reliability RG-AM5528-SF Operating humidity: 10% to 90% RH Humidity Storage humidity: 5% to 95% RH Fan speed regulating and alarm function EN 55032, EN 55035, EN 61000-3-3, EN IEC 61000-3-2, ETSI... -
Page 15: Electrical Safety
Hardware Installation and Reference Guide Installation Preparation Electrical Safety 1.5.3 Warning Irregular and improper electrical operations may cause accidents such as fire or electric shock, and cause serious or fatal injury to human body and device. Do not directly contact high voltage and mains or contact them through wet objects; otherwise, it may bring fatal danger. -
Page 16: Storage Security
Hardware Installation and Reference Guide Installation Preparation fiber optic cable or plugged with a dust cover to prevent dust from entering and burning people's eyes. Do not look directly into the SFP port. Danger Do not approach or look directly into the SFP port in any situation to avoid permanent damage to your eyes. -
Page 17: Temperature And Humidity Requirements
Hardware Installation and Reference Guide Installation Preparation Temperature and Humidity Requirements 1.6.4 To ensure the normal operating of the device and prolong its service life, maintain certain temperature and humidity in the equipment room. If the equipment room is in the environment that does not meet the temperature/humidity requirements for a long time, the device may be damaged. -
Page 18: Grounding Requirements
Hardware Installation and Reference Guide Installation Preparation and component aging. The equipment room should prevent the intrusion of harmful gases (such as sulfur dioxide, hydrogen sulfide, nitrogen dioxide, and chlorine), and the specific limits are as follows: Gas requirements Table 1-5 Average (mg/m³) Maximum (mg/m³) Sulfur dioxide... -
Page 19: Anti-Interference Requirements
heat dissipation of the device chassis. Ruijie devices are equipped with cooling fans. The cooling principle is as follows: cold air is drawn in from the cooling holes around the chassis and exhausted from the rear of the chassis through the fan. -
Page 20: Cabinet Installation Requirements
Hardware Installation and Reference Guide Installation Preparation systems. Ensure that the cabinet and workbench are strong enough to support the device and its mounting accessories. Ensure that the cabinet and workbench are well grounded. Cabinet Installation Requirements If you plan to install the device in the cabinet, confirm that the cabinet meets the following conditions: Use the 19-inch standard cabinet with four posts. -
Page 21: Installation Tools
Multimeter Related devices PC, display, keyboard Note RG-AM5528-SF does not come with a tool kit, so the tools on the tool list need to be prepared by users. Installation Caution Ensure that you have carefully read the contents of Chapter 2, and the requirements described in Chapter 2 have been met. -
Page 22: Cable Connection
Hardware Installation and Reference Guide Verifying Operation Status Confirm the location of the emergency power switch in the room. When an accident occurs, turn off the power switch immediately. Cable Connection 1.11 Warning Use the power cord that is delivered with the device to avoid safety accidents. After the device is installed in the cabinet, you need to connect the device to external device ports by the following steps: Connect the power cord delivered with the device into the system power in turn. -
Page 23: Power-On
Hardware Installation and Reference Guide Monitoring and Maintenance Configuration environment diagram Figure 1-6 Power-on 1.14 Check Before Power-on 1.14.1 Check whether the device is properly grounded. Check whether the fan module and power supply module are properly installed. Check whether the power cord is correctly connected. -
Page 24: Hardware Maintenance
The fan module that is responsible for heat dissipation of the device has a fault monitoring signal. Once a fault occurs, you will be promoted. To replace the fan, contact Ruijie Networks Customer Service Department for technical support, and Ruijie Networks technicians will use a fan of the same specification for replacement. -
Page 25: Appendix
Hardware Installation and Reference Guide Appendix Appendix Connector and Connection Media Description 1.17 1000BASE-T/100BASE-TX/10BASE-T port The 1000BASE-T/100BASE-TX/10BASE-T port is adaptive to three rates, and supports automatic MDI/MDIX Crossover functions at the three rates. 1000BASE-T complies with the IEEE 802.3ab standard, the connected cable is 100-ohm CAT5 or CAT 5e unshielded twisted pair UTP or shielded twisted pair STP. - Page 26 Hardware Installation and Reference Guide Appendix Pinouts of 100BASE-TX/10BASE-T Table 1-7 Socket Connector Input Receive Data+ Output Transmit Data+ Input Receive Data- Output Transmit Data- Output Transmit Data+ Input Receive Data+ Output Transmit Data- Input Receive Data- 4, 5, 7, 8 Not Used Not Used The following are the possible connection methods of straight-through and cross twisted...
-
Page 27: Sfp Module Type And Technical Specifications
Hardware Installation and Reference Guide Appendix SFP Module Type and Technical Specifications 1.18 The corresponding gigabit SFP modules are provided according to the port type of the controller module. You can choose the proper SFP module according to the actual requirements. -
Page 28: Sfp+ Module Description
Hardware Installation and Reference Guide Appendix 2.5G-SFP-LX03-SM1310- Single 9/125 3 km BIDI-I mode Caution For the SFP module of which wiring distances is more than 40 km (including 40 km), if a short-distance single-mode fiber is used, an in-line optical attenuator should be inserted into the link to avoid overloading the optical receiver. - Page 29 Hardware Installation and Reference Guide Appendix 10G SFP+ module type and technical specifications Table 1-11 Transmitted Received Waveleng Intensity Fiber Intensity (dBm) Model (Yes/No (dBm) Type (nm) Multi- XG-SFP-SR-MM850 -7.5 mode XG-SFP-SR-SM1270- Multi- 1270 BIDI mode XG-SFP-SR-SM1330- Multi- 1270 BIDI mode XG-SFP-LR-SM1270- Single...
- Page 30 Hardware Installation and Reference Guide Appendix SFP+ module wiring layout Table 1-12 Core Modal Port Fiber Max. Wiring Specification Bandwidth Model Distance Type Type (um) (MHz·km) 200 (OM1) 33 m 62.5/125 26 m XG-SFP-SR-MM850 Multi-mode 2000 (OM3) 300 m 50/125 500 (OM2) 82 m 400 (OM1)
- Page 31 Hardware Installation and Reference Guide Appendix Caution Do not use short-distance optical fibers for XG-SFP-ER-SM1550 and XG-SFP-ZR-SM1550 to avoid overloading the optical receivers of the modules. If the optical power at the receiving end of the module is greater than or equal to -1 dBm, an appropriate attenuator should be added at the receiving end of the module to make the optical power at the receiving end less than -1 dBm.
-
Page 32: Lightning Protection Of All Optical I-Share Master Ap
Hardware Installation and Reference Guide Appendix Lightning Protection of All Optical i-Share Master AP 1.20 1.20.1 Installation of AC Power Lightning Arrester (Lightning Protection Socket) When the AC power cord is introduced from the outdoors and directly connected to the power port of the all optical i-Share master AP, the AC power port should be connected to an external lightning protection socket to prevent the all optical i-Share master AP from being struck by lightning. -
Page 33: Installation Of Lightning Arrester On Network Port
Hardware Installation and Reference Guide Appendix After the AC power connector of the all optical i-Share master AP is inserted into the socket of the lightning arrester (lightning protection socket), the lightning protection function takes effect only when the running indicator is steady green but not red (red indicates alarming). ... - Page 34 Hardware Installation and Reference Guide Appendix Installation diagram of lightning arrester on network port Figure 1-11 Caution The lightning arrester can only be used on 10/100M Ethernet copper ports (using RJ-45 connector). The lightning arrester is not delivered with the device, so you need to buy it according to the actual needs.
-
Page 35: Wiring During Installation
Wiring During Installation 1.21 When the RG-AM5528-SF series all optical i-Share master AP is installed in a 19-inch standard cabinet, the connected cables are bundled on the cable binding frame of the cabinet through the cable management bracket. Choose upper or lower cabling according to the actual situation of the equipment room. - Page 36 Hardware Installation and Reference Guide Appendix Cable bundling diagram (1) Figure 1-12 Twisted Bending Different types of cables (power cables, signal cables, such as ground cables) should ○ be routed and bound separately in the cabinet. Do not mix them. When the distance is short, cross wiring can be used.
- Page 37 Hardware Installation and Reference Guide Appendix When the cables need to be bent, bind the cables before binding. However, the buckle ○ cannot be bound in the curved part; otherwise, a large stress is generated on the cables and breaks the cable core, as shown in Figure 6-8.
- Page 38 Hardware Installation and Reference Guide Appendix Cable fixing diagram Figure 1-15 Flat washer Flat Spring washer washer For stiff power cords, secure them near the connector to prevent stress on the ○ connector and on the cable. Do not use self-tapping screws to fasten the terminals. ○...
-
Page 39: Suggestions For The Location Of The Equipment Room
Hardware Installation and Reference Guide Appendix Suggestions for the Location of the Equipment Room 1.22 The equipment room should stay away from pollution sources. The distance from the heavy pollution sources such as smelters, coal mines, and thermal power stations should be more than 5 km. - Page 40 Hardware Installation and Reference Guide Appendix The air conditioner in the equipment room should not blow air directly on the device, and it should be avoided that the air conditioner blows the water droplets from windows or vents into the device.
