Ruijie RG-AM5532 Access Point
Hardware Installation and Reference Guide
Document Version: V1.04
Date: August 16, 2023
Copyright © 2023 Ruijie
Networks

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-AM5532 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruijie RG-AM5532

Summary of Contents for Ruijie RG-AM5532

  • Page 1 Ruijie RG-AM5532 Access Point Hardware Installation and Reference Guide Document Version: V1.04 Date: August 16, 2023 Copyright © 2023 Ruijie Networks...
  • Page 2 Some or all of the products, services or features described in this document may not be within the scope of your purchase or use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement or guarantee for the content of this document.
  • Page 3 Preface Intended Audience This document is intended for: Network engineers  Technical support and servicing engineers  Network administrators  Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/  Technical Support Website: https://ruijienetworks.com/support  Case Portal: https://caseportal.ruijienetworks.com  Community: https://community.ruijienetworks.com  Technical Support Email: service_rj@ruijienetworks.com...
  • Page 4 2. Note The manual offers configuration information (including model, port type and command line interface) for indicative purpose only. In case of any discrepancy or inconsistency between the manual and the actual version, the actual version prevails.

  • Page 5: Product Introduction

    IEEE 802.3af or two devices that support IEEE 802.3at for expansion of APs that support standard PoE. Based on the IEEE 802.11 protocol, the RG-AM5532 can provide 24 RF modules by using Category-5 cables to deliver dual-band and two spatial- stream performance for 24 rooms, with 600 Mbps bandwidth for each room.
  • Page 6 Hardware Installation and Reference Guide Product Introduction Rated voltage range: 100 V AC to 240 V AC Maximum voltage range: 90 V AC to 264 V AC Power Supply Frequency: 50/60 Hz Rated current: 3 A EEE Function Supported Supported. Four uplink copper ports can supply power to four devices that support IEEE 802.3af or two devices that support IEEE PoE Function 802.3at.
  • Page 7 2000 m (6561.68 ft.) above sea level. Product Appearance The front panel of the RG-AM5532 provides 24 × 10/100/1000Base-T Ethernet ports, 4 × 1000 Mbps uplink copper ports, 4 × 10 Gbps SFP+ optical ports, and one console port. The rear panel has an AC power connector.
  • Page 8 Port Modes Ports 25 to 32 on the RG-AM5532 can work in three modes. Only a maximum of four ports can work simultaneously in each mode. (1) Mixed mode: two optical ports and two copper ports. As shown in the following figure, ports 27, 28, 31, and 32 are working simultaneously.
  • Page 9  Heat Dissipation Solution The RG-AM5532 adopts the dual-fan design. To ensure proper heat dissipation, maintain a minimum clearance of 10 cm (3.94 in.) around the device for air circulation. To install the AP on a rack, it is recommended to install the AP at a spacing of 1 U. Do not stack the AP. Handle the AP by strictly following the instructions.
  • Page 10 Hardware Installation and Reference Guide Product Introduction LEDs Identifier Description on the Status Panel The RG-AM5532 is not powered on. Blinking The RG-AM5532 is being initialized. green Continuous blinking indicates a fault. Status LED Status Steady green The RG-AM5532 is normally running.
  • Page 11 Hardware Installation and Reference Guide Product Introduction (switching Blinking The port is sending and receiving traffic mode) green at 1000 Mbps. The port has made a successful 10/100 Steady yellow Mbps link. Blinking The port is receiving or sending traffic. yellow 1000 Mbps The port is supplying power to an...

  • Page 12: Preparing For Installation

    Preparing for Installation Safety Precautions Caution To avoid personal injury and device damage, carefully read the safety precautions before you install the RG-AM5532. The following safety precautions may not cover all possible dangers. 2.1.1 General Safety Precautions Keep the chassis clean, free from any dust.

  • Page 13: Installation Environment Requirements

     2.1.5 Laser Safety The RG-AM5532 supports multiple models of optical modules, which are generally Class I optical modules. Optical modules are easily damaged by improper use. Therefore, pay attention to the following precautions when using optical modules. When an optical fiber transceiver works, ensure that its port has been connected with an ...

  • Page 14: Temperature And Humidity Requirements

    In an environment with high temperature, the device performance is greatly degraded and  the device hardware is prone to failures. The following table describes the temperature and humidity requirements for the RG-AM5532 Temperature Relative Humidity 0ºC to 45ºC (32°F to 113°F)

  • Page 15: Anti-Interference Requirements

    Hardware Installation and Reference Guide Preparing for Installation Sulfur dioxide 0.006 0.03 Hydrogen sulfide (H2S) 0.04 0.15 Nitrogen dioxide (NO 0.05 0.15 Ammonia gas (NH 0.01 Chlorine gas (CI Caution Average refers to the average value of harmful gases measured in one week. Maximum refers to the upper limit of harmful gases measured in one week, and the maximum value cannot last for more than 30 minutes every day.

  • Page 16: Lightning Protection Requirements

    To use a lightning arrester, connect the mains AC power cable to the lightning arrester, and then connect the RG-AM5532 to the lightning arrester. To some extent, this can prevent the high-voltage lightning current from...

  • Page 17: Emi Requirements

    Phillips screwdriver, flat-head screwdriver, related Common Tools electric cables and optical cables, fastening bolts, diagonal pliers, and binding straps Special Tools ESD tools Meters Multimeter Caution The RG-AM5532 is delivered without a tool kit. The tool kit and cables are customer-supplied.

  • Page 18: Installing The Device

    Hardware Installation and Reference Guide Installing the Device Installing the Device Caution Before installing the device, make sure that you have carefully read the requirements described in Chapter 2. Ensure that requirements in Chapter 2 are all met. Installation Procedure...

  • Page 19: Before You Begin

    Installing the RG-AM5532 in a Cabinet The RG-AM5532 can be installed in a 19-inch EIA cabinet. The installation steps are as follows: Step 1: Secure one end of a bracket to each side of the RG-AM5532 by using the matching screws. Figure 3-1 Securing Brackets...
  • Page 20 Hardware Installation and Reference Guide Installing the Device Left Right Step 2: Mount the device into the cabinet and secure the other ends of the brackets to square hole posts of the cabinet by using the cage nuts and M6 screws. Figure 3-2Installing Cage Nuts and Screws Figure 3-3Tightening Screws...
  • Page 21 The brackets delivered with the RG-AM5532 can be used to mount the RG-AM5532 onto a wall. The installation steps are as follows: Step 1: Rotate the brackets by 90 degrees and secure the brackets to the RG-AM5532 by using the matching screws.
  • Page 22 Figure 3-5 Securing the RG-AM5532 3.3.3 Installing the RG-AM5532 on a Workbench In most cases, a standard 19-inch cabinet is unavailable. Therefore, a simple way is to place the device on a clean workbench. The installation steps are as follows: Step 1: Attach the four rubber pads to the four corners on the bottom.

  • Page 23: Checking After Installation

    Hardware Installation and Reference Guide Installing the Device Step 2: Place the RG-AM5532 on the workbench with adequate airflow and good heat dissipation. Figure 3-7 Placing the RG-AM5532 Caution The workbench on which the device is installed must be subject to movement restrictions.

  • Page 24: Setting Up The Environment

    Verifying Operating Status Setting up the Environment Setting up the Environment Connect a PC with the console port on the RG-AM5532 by using a network cable, as shown in Figure 4-1. Figure 4-1 Setting up the Environment Connected with the console...
  • Page 25 Hardware Installation and Reference Guide Verifying Operating Status (3) In the Name box, enter the new connection name and click OK. The Connect to dialog box is displayed. From the Connect using drop-down list, select a COM port to be used, as shown in Figure 4-3.
  • Page 26  Check whether the power cord is properly connected.  Check whether the power supply voltage is the same as that required by the RG-AM5532.  Check whether the PC is properly connected with the console port on the RG-AM5532.

  • Page 27: General Troubleshooting Procedure

    Check whether the power supply is properly connected. Check whether the LED is normal. Check whether the serial port is correctly connected and configured. Check whether the cable is correctly connected with each port. Contact Ruijie technical support to check whether hardware faults exist.

  • Page 28: Common Troubleshooting Procedures

    Hardware Installation and Reference Guide Troubleshooting Common Troubleshooting Procedures Symptom Possible Cause Solution Forgotten password The password is Please contact Ruijie forgotten after being manageme technical support. manually configured. nt interface login Check whether the power supply socket in the...
  • Page 29 Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 1000BASE-T/100BASE-TX/10BASE-T Port The 1000BASE-T/100BASE-TX/10BASE-T port is a 10/100/1000 Mbps auto-sensing port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3ab, 1000BASE-T requires 100-ohm Category-5/5e UTP or STP with a maximum distance of 100 meters. The 1000BASE-T port requires all four pairs of wires be connected for data transmission, as shown in the following figure.
  • Page 30 Hardware Installation and Reference Guide Appendix Output Transmit Data+ Input Receive Data+ Output Transmit Data- Input Receive Data- 4, 5, 7, 8 Not Used Not Used The following figure shows wiring of straight-through and crossover cables for 100BASE- TX/10BASE-T. Figure A-3 100BASE-TX/10BASE-T Twisted Pair Connections Optical Fiber Connections Please choose single-mode fibers (SMFs) or multi-mode fibers (MMFs) for connections based on the actual optical module type.
  • Page 31 Hardware Installation and Reference Guide Mini-GBIC and SFP+ Modules Based on the port types of the RG-AM5532, Ruijie provides corresponding SFP modules (Mini-GBIC modules) and 10G SFP+ modules. Customers can select modules based on usage requirements. In addition to the following modules, the O/E conversion 1000M SFP module Mini-GBIC-GT is supported.
  • Page 32 Hardware Installation and Reference Guide Mini-GBIC-LH40 1310 Mini-GBIC-ZX50 1550 Mini-GBIC-ZX80 1550 Mini-GBIC-ZX100 1550 Cabling Specifications Waveleng Cable Max. Cabling Model Core Size (μm) th (nm) Type Distance 62.5/125 275 m Mini-GBIC-SX 50/125 550 m Mini-GBIC-LX 1310 9/125 10 km 62.5/125 275 m GE-eSFP-SX-MM850 50/125...
  • Page 33 Hardware Installation and Reference Guide GE-SFP-LH40-SM1310-BIDI 1000 Mbps/40 km GE-SFP-LH40-SM1550-BIDI Caution BIDI modules must be used in pairs. If FE-SFP-LX20-SM1310-BIDI is used at one end, then FE-SFP-LX20- SM1550-BIDI must be applied to the other end. Table B-4 Mini-GBIC-GT Modules and Specifications Available SFP modules Standard 1000Base-T SFP Module...
  • Page 34 Hardware Installation and Reference Guide XG-SFP- 1310 10 km -8.2 LR-SM1310 10.3 conne ctor) XG-SFP- 1550 40 km -4.7 ER-SM1550 11.3 conne ctor) XG-SFP- 1550 80 km ZR-SM1550 conne ctor) Available 10GE SFP+ DAC modules Supp Conductor Modu Conne Cable Wire Speed Model...

  • Page 35: Lightning Protection

    Make sure that the PE terminal of the AC surge protector is well grounded.  After the AC power plug of the RG-AM5532 is connected with the socket of the AC surge  protector (lightning arrester), the lightning protection function is implemented only if the RUN LED is green and the ALARM LED is OFF.
  • Page 36 AC surge protector has not been grounded. Installing an Ethernet Port Arrester Please connect an Ethernet port arrester with the RG-AM5532 to prevent the damage caused by lightning before connecting an outdoor network cable with the RG-AM5532.
  • Page 37 The Ethernet port arrester is only for the 10/100 Mbps copper ports with an RJ45 connector. The Ethernet port arrester is not delivered with the RG-AM5532. Please purchase it based on actual requirements. For details about the technical specifications, installation procedure, and maintenance of the Ethernet port arrester, see the corresponding user guide.

  • Page 38: Cabling Recommendations

    Hardware Installation and Reference Guide Cabling Recommendations When the RG-AM5532 is installed in a standard 19-inch cabinet, secure the cables around the cable management brackets. Top cabling or bottom cabling is adopted according to the actual situation in the equipment room. All cable connectors should be placed at the bottom of the cabinet rather than be exposed outside of the cabinet.
  • Page 39 Hardware Installation and Reference Guide Twisting Bending Cables of different types (such as power cables, signal cables, and ground cables) should  be separated in cabling and bundling. Mixed bundling is not allowed. When they are close to each other, it is recommended to adopt crossover cabling. In the case of parallel cabling, maintain a minimum distance of 30 mm (1.18 in.) between power cords and signal cables.
  • Page 40 Hardware Installation and Reference Guide When cables need to be bent, bind them first but do not tie cable ties within the bend to  avoid stress on the cables, which may otherwise cause the wires inside to break, as shown in Figure D-3.
  • Page 41 Hardware Installation and Reference Guide When screw threads are used to fasten cable terminals, the bolt or screw must be tightly  fastened, and anti-loosening measures should be taken, as shown in Figure D-4. Figure D-4 Fastening Cables Flat washer Spring Flat washer...

  • Page 42: Site Selection

    Hardware Installation and Reference Guide Site Selection The equipment room should be at least 5 km away from heavy pollution sources, such as  the smelter works, coal mine, and thermal power plant. The equipment room should be at least 3.7 km away from medium pollution sources, such as the chemical factory, rubber factory, and electroplating factory.
  • Page 43 Hardware Installation and Reference Guide drops from the window or vent into the device.
