Step 1 - Inventory Of Parts - Uplift Desk V2 F500 C-Frame Manual

Step 1 - Inventory of Parts

A. To avoid damage to your floor or desktop, assemble the
desk on a clean carpet or blanket.
B. Lay out all parts from each box and ensure you have
everything listed in the package contents of this manual
before throwing away any packaging.
If a part is missing, please triple check that the part
isn't in a box. Check boxes very thoroughly by removing
all packaging; check every nook and cranny. If the part
is still missing, call (800) 349-3839 or email support@
upliftdesk.com before beginning assembly.
Step 2 - Attach Crossbar Ends
A. Position a Crossbar End
B. Position a Leg (P4) so that the back of the Leg is flush
with the back of the Crossbar End.
C. Use the 4mm Allen Wrench
10 Machine Screws (H1)
the Crossbar End and into the threaded holes in the sides
of the Leg, but do not tighten the screws yet.
Step 3 - Attach Side Brackets
A. Position a Side Bracket
into the openings at the back of the Crossbar End (P5).
Loosely start two M6 x 10 Machine Screws
the holes in the top of the Crossbar End and into the
threaded holes in the top of the Side Bracket tabs, but do
not tighten the screws yet.
B. Loosely start two more M6 x 10 Machine Screws through
the two larger holes in the face of the Side Bracket and
into the threaded holes in the back of the Leg.
C. Tighten all eight screws from Steps 2 and 3 with the 4mm
Allen Wrench (H6).
D. Repeat Steps 2 and 3 to attach the second Crossbar End
and Side Bracket.
IMPORTANT: Ensure all screws are tight before
proceeding.
6
Assembly Instructions
(P5) as shown.
(H6) to loosely start four M6 x
through the holes in the sides of
(P2) as shown and insert the tabs
(H1) through
P4
H1
C
H1
T
C-Frame side bracket is shown; the steps
are the same if you have a T-Frame.
C
T
H1
C-Frame side bracket is shown; the steps
are the same if you have a T-Frame.
P5
H1
P2
right
